膨润土膨胀变形的分形模型

徐永福; 项国圣; 褚飞飞; 吴蓉

doi:10.13544/j.cnki.jeg.2014.05.02

膨润土膨胀变形的分形模型

doi: 10.13544/j.cnki.jeg.2014.05.02

1.
上海交通大学土木工程系上海 200240;
2.
河海大学文天学院岩土工程研究所马鞍山 243000

基金项目:

国家自然科学基金（41272318和41472251）资助

详细信息

作者简介:
徐永福（1967- ），男，博士，教授，博士生导师，主要从事非饱和土力学、分形介质力学和特殊土地基处理研究. Email: yongfuxu@sjtu.edu.cn

中图分类号: TU47
计量
- 文章访问数: 3257
- HTML全文浏览量: 220
- PDF下载量: 780
- 被引次数: 0
出版历程
- 收稿日期: 2014-05-12
- 修回日期: 2014-09-05
- 刊出日期: 2014-10-25

FRACTAL MODEL FOR SWELLING DEFORMATION OF BENTONITE

1.
Department of Civil Engineering, Shanghai Jiaotong University, Shanghai 200240;
2.
Institute of Geotechnical Engineering, Wentian College, Hohai University, Maanshan 243000

摘要

摘要: Xu等[1] 提出基于膨润土表面分形模型的膨胀变形计算方法 Vw／Vm=kPDs-3(式1)，并得到了Tsukinuno膨润土、Wyoming膨润土和MX-80膨润土的膨胀变形和膨胀压力(统称膨胀变形)的膨胀试验数据的验证。当时由于条件限制，存在两个问题：(1)膨润土的表面分维一般采用氮吸附法测量，由膨胀变形试验数据反算得到的膨润土表面分维没有得到氮吸附试验数据的验证； (2)在归一化吸水体积与压力的分形模型(式1)中，K是膨润土的物性常数，没有给出理论表达式，只是经验系数。本文采用氮吸附方法测量了高庙子Na基膨润土、高庙子Ca基膨润土、商用膨润土和Tsukinuno膨润土的表面分维，根据式(1)由表面分维计算膨胀变形，并与膨胀试验数据比较，验证膨胀变形的分形模型；根据双电层理论，导出用双电层参数表示式(1)中K值的理论表达式，用于膨胀变形的计算，并与膨胀变形试验结果进行比较验证。
- 膨润土 /
- 膨胀变形 /
- 分形 /
- 表面分维 /
- 氮吸附
Abstract: On the base of the fractal model for bentonite surface, Xu et al.[1] proposed a new method to calculate the swelling deformation of bentonite and expressed as the equation Vw/Vm=KpDs-3(Eq.(1)),which were verified by the experimental data of swelling deformation and swelling pressure of Tsukinuno bentonite, Wyoming bentonite and MX-80 bentonite. Due to the limitation of experiments, two factors to be improved are listed as follows：(1)the fractal dimension obtained from the swelling test was not validated with results of the N2 isotherm adsorption; (2)the expression of the parameter K in Eq.(1)was given on the basis of an empirical equation. In this paper, the surface fractal dimension of Gaomiaozi Na-bentonite and Ca-bentonite, a commercial bentonite and Tsukinuno bentonite are measured using the N2 isotherm adsorption. The swelling deformation is calculated and verified from the above equation using the surface fractal dimension of Gaomiaozi Na-bentonite and Ca-bentonite, a commercial bentonite and Tsukinuno bentonite. Expression of the parameter K in the above equation is deduced from the diffused double layer(DDL)theory.
- Bentonite /
- Swelling deformation /
- Fractal /
- Surface fractal dimension /
- N2 adsorption

HTML全文

参考文献(1)

[1] Xu Y F,Matsuoka H,Sun D A.Swelling characteristics of fractal-textured bentonite and its mixtures[J]. Applied Clay Science, 2003, 22 : 197～209.

[2] 孙德安, 邵莉娜. 高庙子膨润土和砂混合物膨胀变形特性及其预测[J]. 上海大学学报(自然科学版), 2013, 19 (2): 197～202.

Sun De'an, Shao Lina. Swelling deformation character-istics of Gaomiaozi bentonite-sand mixtures and its prediction[J]. Journal of Shanghai University(Natural Science), 2013, 19 (2): 197～202.

[3] 叶为民,Schanz T,钱丽鑫,等. 高压实高庙子膨润土GMZ01的膨胀力特征[J]. 岩石力学与工程学报, 2007, 26 (增2): 3861～3865.

Ye Weimin, Schanz T,Qian Lixin,et al. Characteristics of swelling pressure of densely compacted Gaomiaozi bentonite GMZ01[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26 (S2): 3861～3865.

[4] 叶为民, 赖小玲,刘毅,等. 高庙子膨润土膨胀力时效性试验研究[J]. 岩土工程学报, 2013, 35 (12): 17～22.

Ye Weimin, Lai Xiaoling, Liu Yi, et al. Experimental study on ageing effects on micro-structure of unsaturated GMZ01 bentonite[J]. Chinese Journal of Geotechnical Engineering, 2013, 35 (12): 17～22.

[5] 秦冰, 陈正汉,刘月妙,等. 高庙子膨润土的胀缩变形特性及其影响因素研究[J]. 岩土工程学报, 2008, 30 (7): 1005～1010.

Qin Bing, Chen Zhenghan, Liu Yuemiao, et al. Swelling-shrinkage behaviour of Gaomiaozi bentonite[J]. Chinese Journal of Geotechnical Engineering, 2008, 30 (7): 1005～1010.

[6] Komine H,Ogata N.New equation for swelling characteristics of bentonite-based buffer materials[J]. Canadian Geotechnical Journal, 2003, 40 : 460～475.

[7] Yong R N,Warkentin B P. Soil properties and behaviour[M]. Amsterdam: Elsevier, 1975.

[8] Sposito G. The surface chemistry of soils[M]. New York: Oxford University Press, 1984.

[9] Bolt G H.Physico-chemical analysis of the compressibility of pure clay[J]. Geotechnique, 1956, 6 (2): 86～93.

[10] Kahr G,Kraehenbuehl F,Stoeckli H F.Study of the water-bentonite system by vapour adsorption, immersion colorimetry and X-ray technique[J]. Clay Minerals, 1990, 25 : 499～506.

[11] Avnir D,Jaroniec M.An isotherm equation for adsorption on fractal surfaces of heterogeneous porous materials[J]. Langmuir, 1989, 5 : 1431～1433.

[12] Yong R N.Soil suction and soil-water potential in swelling clays in engineered clay barriers[J]. Eng. Geol., 1999, 54 (1-2): 3～13.

[13] Studds P G,Stewart D I,Cousens T W.The effects of salt solutions on the properties of bentonite-sand mixtures[J]. Clay Minerals., 1998, 33 : 651～660.

[14] Liu L,Neretnieks I.Homo-interaction between parallel plates at constant charge[J]. Colloids and Surfaces A:Physico chemical and Engineering Aspects, 2008, 317 (1): 636～642.

[15] Xu Y F,Sun D A,Yao Y P.Surface fractal dimension of bentonite and its application to determination of swelling properties[J]. Chaos, Solitons and Fractals, 2004, 19 : 347～356.
