花岗岩地区地铁隧道爆破振动传播规律研究

翟才雅; 李安龙; 刘涛; 苏宇

doi:10.13544/j.cnki.jeg.2014.05.08

花岗岩地区地铁隧道爆破振动传播规律研究

doi: 10.13544/j.cnki.jeg.2014.05.08

翟才雅¹,
李安龙¹,
刘涛^2,3, ,,
苏宇²

1.
中国海洋大学海洋地球科学学院青岛 266000;
2.
中国海洋大学环境科学与工程学院青岛 266000;
3.
同济大学岩土及地下工程教育部重点实验室上海 200000

基金项目:

国家自然科学基金资助项目（41202204）;同济大学岩土及地下工程教育部重点实验室开放研究基金资助项目（KLE-TJGE-B1107）资助

详细信息

作者简介:
翟才雅（1989- ），男，广西钦州人，硕士在读。Email：beyondzhai2103@sina.com

通讯作者:
刘涛（1979- ），男，博士，副教授，硕士生导师，主要从事地下工程与隧道等教学与科研工作。Email: ltmilan@163.com

中图分类号: U44
计量
- 文章访问数: 3223
- HTML全文浏览量: 146
- PDF下载量: 508
- 被引次数: 0
出版历程
- 收稿日期: 2014-05-20
- 修回日期: 2014-08-28
- 刊出日期: 2014-10-25

VIBRATION PROPAGATION OF TUNNEL BLASTING IN GRANITE AREAS

ZHAI Caiya¹,
LI Anlong¹,
LIU Tao^{2,3
, ,},
SU Yu²

1.
College of Marine Geosciences, Ocean University of China, Qingdao 266000;
2.
College of Environmental Science and Engineering, Ocean University of China, Qingdao 266000;
3.
The Ministry of Education, Tongji University, Key Laboratory of Geotechnical and Underground Engineering, Shanghai 200000

摘要

摘要: 青岛为典型花岗岩地区，地铁隧道开挖采用钻爆法。本文首先采用现场实测与统计分析的方法分析了青岛地铁3号线3个工点的隧道爆破监测数据，较为系统地研究了钻爆法施工条件下地表及邻近构筑物的最大振速、主频分布与爆破参数的相关关系，采用线性回归法拟合出包含上述因素的经验公式。采用数值模拟手段，模拟爆破条件下地表及临近建筑物的振动的响应，并将模拟结果与实测数据进行对比，研究主要结论如下：(1)最大振速随比例距离基本呈指数的形式衰减，随着比例距离的增加，最大振速值逐渐减小； (2)爆破引起的振动主频随比例距离分布较为随机，无法建立两者之间的数学模型，主频多在20～70Hz范围内； (3)建筑物内部中三矢量方向上的最大振速均随着楼层的增高呈一定的增加趋势，建筑物外部的地表振速要大于内部质点的速度。
- 花岗岩地区 /
- 地铁隧道 /
- 钻爆法 /
- 振动传播规律
Abstract: Qingdao is the typical granite region, which uses the drill and blast method to the excavate tunnel. Firstly, the article analyzes the measured blasting data of 3 work site which belong to Qingdao Metro Line 3 using field measurement and statistical analysis. The correlation between vibration velocity of surface and neighboring buildings and the frequency characteristics caused by blasting of blasting distance and dose were researched. The empirical formula including the above factors was concluded by regression analysis. The numerical modeling method was used to research the influence of blast to surface and neighboring buildings, and the simulate particle vibration data was compared with the measured by numerical simulation. The main conclusions are as follows：(1)with the increase of blasting distance, the maximum vibration velocity of surface particle decreases in the form of index attenuation.(2)the vibration frequency caused by blasting is distributing randomly with scaled distance, therefore it is unable to establish the mathematical model between them, and the dominant frequency mostly ranges from 20 to 70 Hz.(3)with the stories increase, the maximum vibration velocity of three-vectors has the magnifying trend. The maximum vibration velocity of the particle inside the building is generally less than the particle closing to the building exterior surface.
- Granite areas /
- Subway tunnel /
- Drill and blast method /
- Vibration propagation

HTML全文

参考文献(1)

[1] 汪旭光. 中国典型爆破工程与技术[M]. 北京:冶金工业出版社, 2006.

Wang Xuguang. China typical blasting and technology[M]. Beijing: Metallurgical Industry Press, 2006.

[2] 于亚伦. 工程爆破理论与技术[M]. 北京:冶金工业出版社, 2004.

Yu Yalun. Blasting theory and technology[M]. Beijing: Metallurgical Industry Press, 2004.

[3] 陈宝心,杨勤荣. 爆破动力学基础[M]. 武汉:湖北科学技术出版社, 2005.

Chen Baoxin, Yang Qinrong. Blasting dynamics basis[M]. Wuhan: Hubei Science and Technology Press, 2005.

[4] 铁道部隧道工程局. 隧道与地下工程施工技术安全管理和操作控制要点[S]. 北京:中国铁道出版社, 1993

Ministry of Railways Tunnel Engineering Bureau. Tunnel and underground construction technology security management and operational control points[S]. Beijing: China Railway Press, 1993.

[5] 言志信. 结构拆除及爆破振动效应研究[D]. 重庆:重庆大学, 2002.

Yan Zhongxin. Study on structure demolition and blast vibration effect . Chongqing: Chongqing University, 2002.

[6] Charles H D. Blast Vibration Monitoring and control[M]. Amsterdam: North-Holland Publishing Company, 1985.

[7] Farhoomand E W. A nonlinear finite element code for analyzing the blast response of underground structures[M]. California: University of California Berkeley, 1970.

[8] Richards A B,Moore A J. The Effect of blast design on vibration frequencies[M]: 502～509.

[9] Charles H D. Suggested method for blast monitoring[J]. Int. J.Rock mech. Min. Sci.& Geo mech. Abstr, 1992, 29 (2): 143～156.

[10] 许红涛, 卢文波. 几种爆破振动安全判据[J]. 爆破, 2002, 19 (1): 5～9.

Xu Hongtao , Lu Wenbo. Advance on safety criteria for blasting vibration . Blasting, 2002, 19 (1):5～9.

[11] 苏宇. 隧道爆破振动对地表及临近建筑物影响研究[D]. 青岛: 中国海洋大学, 2012.

Su Yu. Study on influence of tunnel blasting vibration on ground particles and adjacent buildings . Qingdao: Ocean University of China, 2012.

[12] 王利, 王海亮. 隧道爆破不同类型最大振速对建筑物的影响研究[J]. 爆破, 2012, 29 (4): 6～9.

Wang Li, Wang Hailiang. Influence of different direction vibration peak velocity of tunnel blasting on building . Blasting, 2012, 29 (4):6～9.

[13] 李玉民, 倪芝芳. 地下工程开挖爆破的地面振动特征[J]. 岩石力学与工程学报, 1997, 16 (3): 274～278.

Li Yumin, Ni Zhifang. Ground vibration characteristics of excavation blasting for underground engineering[J]. Chinese Journal of Rock Mechanics and Engineering, 1997, 16 (3): 274～278.

[14] 陈庆, 王宏图,胡国忠,等. 隧道开挖施工的爆破振动监测与控制技术[J]. 岩土力学, 2005, 26 (6): 964～967.

Chen Qing, Wang Hongtu, Hu Guozhong, et al. Monitoring and controlling technology for blasting vibration induced by tunnel excavation[J]. Rock and Soil Mechanics, 2005, 26 (6): 964～967.

[15] 谢全敏, 夏元友,李新平. 龙滩水电站蠕变边坡的爆破振动控制研究[J]. 岩石力学与工程学报, 2003, 22 (11): 1929～1930.

Xie Jinmin, Xia Yuanyou, Li Xinping. Study of blasting vibration control of creep mass slope of Longtanmhydropower stating[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22 (11): 1929～1930.

[16] 言志信, 吴德伦,王漪,等. 地震效应及安全研究[J]. 岩土力学, 2004, 23 (2): 201～203.

Yan Zhixin, Wu Delun, Wang Yi, et al. Study of blast vibration effect and safety[J]. Rock and Soil Mechanics, 2004, 23 (2): 201～203.
