构造煤的成因属性分类

邓绪彪; 胡青峰; 魏思民

doi:10.13544/j.cnki.jeg.2014.05.34

构造煤的成因属性分类

doi: 10.13544/j.cnki.jeg.2014.05.34

1.
华北水利水电大学资源与环境学院郑州 450011;
2.
中国矿业大学北京煤炭资源与安全开采国家重点实验室北京 100083

基金项目:

国家自然科学基金项目（41301598）和华北水利水电学院自主科研项目（201111-001375）资助

详细信息

作者简介:
邓绪彪（1980- ），男，博士，讲师，主要从事岩石力学、构造地质及矿山动力灾害机理及预测方面的研究工作. Email: southhero@qq.com

中图分类号: P618.11
计量
- 文章访问数: 4573
- HTML全文浏览量: 396
- PDF下载量: 696
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-17
- 修回日期: 2014-08-25
- 刊出日期: 2014-10-25

GENESIS AND PROPERTY CLASSIFICATION OF TECTONIC COAL

1.
School of Resources and Environment, North China University of Water Resources and Electric Power, Zhengzhou 450011;
2.
College of Geosciences and Surveying Engineering, China University of Mining and TechnologyBeijing, beijing 100083

摘要

摘要: 前人研究认为构造煤是煤与瓦斯突出的必要条件，构造煤的分类对煤与瓦斯突出的预测和防治有重要意义。(1)根据构造煤参与煤与瓦斯突出过程的突出属性对构造煤重新进行了定义，认为构造煤是构造作用下强度降低、瓦斯异常的煤气双重介质，据此将构造煤划分为01类瓦斯构造煤和01类强度构造煤以及强度和瓦斯都变异的02类构造煤。(2)参考地质构造成因环境下岩石破坏的脆韧性划分方式，将突出属性分类与脆韧性的构造成因特性结合起来，划分出3类脆性构造煤和3类韧性构造煤，分别命名为01类脆性瓦斯构造煤、02类脆性构造煤等。(3)分析了构造煤在煤与瓦斯突出中的作用，低强度构造煤在其周围形成应力集中，瓦斯通过孔隙压力和吸附作用降低煤体强度，而高压瓦斯则是突出发展过程中煤体破坏和抛掷的重要动力源之一。(4)结合成因属性构造煤分类对各种地质因素对构造煤空间分布、构造煤瓦斯的生成和保存条件进行了分析。
- 构造煤 /
- 煤与瓦斯突出 /
- 成因属性分类 /
- 脆性破坏 /
- 韧性破坏
Abstract: It is well-acknowledged that the tectonic coal is necessary for the occurrence of a coal and gas outburst. Therefore, a good classification of the tectonic coal is significant to the prediction and precaution of the outburst. It firstly gives a new definition about tectonic coal according to the mechanical properties appeared by the tectonic coal during the outburst, which is a two-phase material combined by gas and coal, and characterized by low strength and different gas content from the origin coal. With these characters, three types tectonic coal are classified as 01 gas tectonic coal(01 GTC), 01 strength tectonic coal(01 STC) and 02 tectonic coal(02 TC),respectively correspond to coal with high gas content only, low strength only and both. Secondly, six types of genesis property tectonic coal are classified when combined the mechanical property classification and the brittle and ductile of rock failure, which is the traditional geology classification of rock failure form. It embodied three brittleness tectonic coals and three ductile tectonic coals, named as 01 brittle GTC(01 BGTC), 02 GTC,et al. Thirdly, it investigates the mechanism of the attendance in outburst by different tectonic coal. The stress concentration around STC,gas pore pressures and absorption weaken the effect on the coal. The high gas pressure to destroy and throw the coal are distinctive. Finally, based on the genesis property classification, it carries out a thorough investigation about the influence on the TC distribution and its gas genesis and storage condition by geology factors.
- Tectonic coal /
- Coal gas outburst /
- Genesis property classification /
- Brittle failure /
- Ductile failure

HTML全文

参考文献(1)

[1] 韩德馨,任德贻,王延斌,等. 中国煤岩学[M]. 徐州:中国矿业大学出版社, 1996.

Han Dexin, Ren Deyi, Wang Yanbin, et al. Coal petrology of China[M]. Xuzhou: China University of Mining and Technology Press, 1996.

[2] 琚宜文,姜波,王桂梁,等. 构造煤结构及储层物性[M]. 徐州:中国矿业大学出版社, 2005.

Ju Yiwen, Jiang Bo, Wang Guiliang, et al. Tectonic coals: structures and physical properties of reservoirs[M]. Xuzhou: China University of Mining and Technology Press,2005.

[3] 王凯,俞启香. 煤与瓦斯突出的非线性特征及预测模型[M]. 徐州:中国矿业大学出版社, 2005.

Wang Kai, Yu Qixiang. Non-linear characteristic and prediction model of coal and gas outburst[M]. China University of Mining and Technology Press, 2005.

[4] 周世宁,林柏泉. 煤层瓦斯赋存与流动理论[M]. 北京:煤炭工业出版社, 1997.

Zhou Shining, Lin Baiquan. The theory of gas flow and storage in coal seams[M]. Beijing: Coal Industry Press, 1997.

[5] 曹运兴, 彭立世. 顺煤断层的基本类型及其对瓦斯突出带的控制作用[J]. 煤炭学报, 1995, 20 (4): 414～418.

Cao Yunxing, Peng Lishi. Basic types of coal seam faults and their effect on controlling gas outburst zone[J]. Journal of China Coal Society, 1995, 20 (4): 414～418.

[6] 张子敏,林又玲,吕绍林. 中国煤层瓦斯分布特征[M]. 北京:煤炭工业出版社, 1998.

Zhang Zimin, Lin Youling,Lü Shaolin. Distribution character of Chinese coal-bed methane[M]. Beijing: Coal Industry Press, 1998.

[7] 郭德勇, 韩德馨. 煤与瓦斯突出黏滑机理研究[J]. 煤炭学报, 2003, 28 (6): 598～602.

Guo Deyong, Han Dexin. The stick-slip mechanism of coal and gas outburst[J]. Journal of China Coal Society, 2003, 28 (6): 598～602.

[8] 张玉贵, 张子敏,曹运兴. 构造煤结构与瓦斯突出[J]. 煤炭学报, 2007, 32 (3): 281～284.

Zhang Yugui, Zhang Zimin, Cao Yunxing. Deformed-coal structure and control to coal-gas outburst[J]. Journal of China Coal Society, 2007, 32 (3): 281～284.

[9] 王恩营, 刘明举,魏建平. 构造煤成因—结构—构造分类新方案[J]. 煤炭学报, 2009, 34 (5): 656～660.

Wang Enying, Liu Mingju, Wei Jianping. New genetic-texture-structure classification system of tectonic coal[J]. Journal of China Coal Society, 2009, 34 (5): 656～660.

[10] 韩德馨,杨起. 中国煤田地质学(上)——煤田地质基础理论[M]. 北京:煤炭工业出版社, 1979.

Han Dexin, Yang Qi. Chinese coalfield geology(I):basic theory of coalfield geology[M]. Beijing: Coal Industry Press, 1979.

[11] 俞启香. 矿井瓦斯防治[M]. 徐州:中国矿业大学出版社, 1992.

Yu Qixiang. Precaution to the mine gas[M]. China University of Mining and Technology Press, 1992.

[12] 张文佑. 断块构造导论[M]. 北京:石油工业出版社, 1984.

Zhang Wenyou. An introduction to fault -block structures[M]. Beijing: Petroleum Industry Press, 1984.

[13] 孙广忠. 岩体结构力学[M]. 北京:科学出版社, 1988.

Sun Guangzhong. Rock structural mechanics[M]. Beijing: Science Press, 1988.

[14] 梁冰, 章梦涛,潘一山,等. 瓦斯对煤的力学性质及力学影响的试验研究[J]. 岩土工程学报, 1995, 17 (5): 12～18.

Liang Bing, Zhang Mengtao, Pan Yishan, et al. The experimental research on the effect of gas on mechanical properties and mechanical response of coal[J]. Chinese Journal of Geomechanics Engineering, 1995, 17 (5): 12～18.

[15] 傅雪海, 秦勇,姜波,等. 多相介质煤岩体力学实验研究[J]. 高校地质学报, 2002, 8 (4): 446～452.

Fu Xuehai, Qin Yong, Jiang Bo, et al. Study on mechanics experiments of multiphase medium coal rocks[J]. Geological Journal of China Universities, 2002, 8 (4): 446～452.

[16] 丁晓良, 俞善炳,丁雁生,等. 煤在瓦斯渗流作用下持续破坏的机制[J]. 中国科学(A辑), 1989, 6 : 600～607.

Ding Xiaoliang, Yu Shanbing, Ding Yansheng, et al. The continual failure of coal under the seepage action by gas[J]. Science China(A), 1989, 6 : 600～607.

[17] 鲜学福, 辜敏,李晓红,等. 煤与瓦斯突出的激发和发生条件[J]. 岩土力学, 2009, 30 (3): 577～581.

Xian Xuefu, Gu Min, Li Xiaohong, et al. Excitation and occurrence conditions for coal and gas outburst[J]. Rock and Soil Mechanics, 2009, 30 (3): 577～581.

[18] 景国勋, 张强. 煤与瓦斯突出过程中瓦斯作用的研究[J]. 煤炭学报, 2005, 30 (2): 169～171.

Jing Guoxun, Zhang Qiang. Study on the role of gas in the coal and gas outburst[J]. Journal of China Coal Society, 2005, 30 (2): 169～171.

[19] 刘俊来, 杨光,马瑞. 高温高压实验变形煤流动的宏观与微观力学表现[J]. 科学通报, 2005, 50 (增1): 56～63.

Liu Junlai, Yang Guang, Ma Rui. Macro & micro mechanical characters of deformed-coal experiment under high pressure and temperature[J]. Chinese Science Bulletin, 2005, 50 (S1): 56～63.

[20] 张国成, 熊明富,郭卫星,等. 淮南矿区井田小构造对煤与瓦斯突出的控制作用[J]. 焦作工学院学报(自然科学版), 2003, 22 (5): 329～333.

Zhang Guocheng, Xiong Mingfu, Guo Weixing, et al. Small-scale structures controlling coal and gas outburst in Huainan Coal Field[J]. Journal of Jiaozuo Institute of Technology(Natural Science), 2003, 22 (5): 329～333.

[21] 郭德勇, 韩德馨. 地质构造控制煤和瓦斯突出作用类型研究[J]. 煤炭学报, 1998, 23 (4): 337～341.

Guo Deyong, Han Dexin. Research on the types of geological tectonic controlling coal-gas outbursts[J]. Journal of China Coal Society, 1998, 23 (4): 337～341.

[22] 刘咸卫, 曹运兴,刘瑞,等. 正断层两盘的瓦斯突出分布特征及其地质成因浅析[J]. 煤炭学报, 2000, 25 (6): 571～575.

Liu Xianwei, Cao Yunxing, Liu Rui. Analysis on distribution features of gas outburst from two walls of normal fault and geological origin[J]. Journal of China Coal Society, 2000, 25 (6): 571～575.

[23] 邵强, 王恩营,王红卫,等. 构造煤分布规律对煤与瓦斯突出的控制[J]. 煤炭学报, 2010, 35 (2): 250～254.

Shao Qiang, Wang Enying, Wang Hongwei, et al. Control to coal and gas outburst of tectonic coal distribution[J]. Journal of China Coal Society, 2010, 35 (2): 250～254.

[24] 张子敏. 瓦斯地质学[M]. 徐州:中国矿业大学出版社, 2009.

Zhang Ziming. Gas geology[M]. China University of Mining and Technology Press, 2009.

[25] 吴基文. 层滑构造及其对煤层的影响[J]. 太原理工大学学报, 1998, 29 (6): 644～647.

Wu Jiwen. Study on the influence of interlayer-gliding structure on coal seam[J]. Journal of Taiyuan University of Technology, 1998, 29 (6): 644～647.

[26] 姚多喜, 吴基文,张海阁. 孟庄井田的层滑构造及其形成机制分析[J]. 煤田地质与勘探, 2002, 30 (2): 16～18.

Yao Duoxi, Wu Jiwen, Zhang Haige. The analysis of seam-gliding structure and deformation mechanism in Mengzhuang mining field[J]. Coal Geology & Exploration, 2002, 30 (2): 16～18.

[27] 琚宜文, 姜波,王桂梁,等. 层滑构造煤岩体微观特征及其应力应变分析[J]. 地质科学, 2004, 39 (1): 50～62.

Ju Yiwen, Jiang Bo, Wang Guiliang, et al. Characteristics of microcosm of interlayer-gliding tectonic coal-tectonite and their stress-finite strain analyses[J]. Chinese Journal of Geology, 2004, 39 (1): 50～62.

[28] 琚宜文, 谭静强,侯泉林,等. 煤层流变研究现状及发展趋势[J]. 中国煤炭地质, 2008, 20 (10): 7～10.

Ju Yiwen, Tan Jingqiang, Hou Quanlin, et al. Research situation and development trend of coalbed rehology[J]. Coal Geology of China, 2008, 20 (10): 7～10.

[29] 宋岩, 赵孟军,柳少波,等. 构造演化对煤层气富集程度的影响[J]. 科学通报, 2005, 50 (增1): 1～5.

Song Yan, Zhao Mengjun, Liu Shaobo, et al.Influence to coal-bed methane enrichment by tectonism development[J]. Chinese Science Bulletin, 2005, 50 (S1): 1～5.

[30] 宋岩, 秦胜飞,赵孟军. 中国煤层气成藏的两大关键地质因素[J]. 天然气地球科学, 2007, 18 (4): 545～553.

Song Yan, Qin Shengfei, Zhao Mengjun. Two key geological factors controlling the coalbed methane reservoirs in China[J]. Natural Gas Geology, 2007, 18 (4): 545～553.

[31] 宋岩, 柳少波,赵孟军,等. 煤层气藏边界类型成藏主控因素及富集区预测[J]. 天然气工业, 2009, 29 (10): 5～11.

Song Yan, Liu Shaobo, Zhao Mengjun, et al. Coalbed gas reservoirs: Boundary types, main controlling factors of gas pooling, and forecast of gas-rich areas[J]. Natural Gas Industry, 2009, 29 (10): 5～11.

[32] 秦勇, 傅雪海,吴财芳,等. 高煤级煤储层弹性自调节作用及其成藏效应[J]. 科学通报, 2005, 50 (增1): 82～86.

Qin Yong, Fu Xuehai, Wu Caifang, et al. The coal matrix flexibility and its reservoir effect in high coal grades[J]. Chinese Science Bulletin, 2005, 50 (S1): 82～86.

[33] 吴财芳, 秦勇,傅雪海,等. 煤基块弹性能及其与地质控制因素之间的关系[J]. 中国矿业大学学报, 2005, 34 (5): 636～639.

Wu Caifang, Qin Yong, Fu Xuehai, et al. Coal matrix flexibility energy and the relation with geological controlling factors[J]. Journal of China University of Mining & Technology, 2005, 34 (5): 636～639.

[34] 秦胜飞, 宋岩,唐修义,等. 流动的地下水对煤层含气性的破坏机理[J]. 科学通报, 2005, 50 (增1): 99～103.

Qin Shengfei, Song Yan, Tang Xiuyi, et al. The destroy mechanism of gas content in coalbed by flowing ground water[J]. Chinese Science Bulletin, 2005, 50 (S1): 99～103.

[35] 秦勇, 傅雪海,岳巍,等. 沉积体系与煤层气储盖特征之关系探讨[J]. 古地理学报, 2000, 2 (1): 78～84.

Qin Yong, Fu Xuehai, Yue Wei, et al. Relationship between depositional systems and characteristics of coalbed gas reservoir and its cap rock[J]. Journal of Palaeogeography, 2000, 2 (1): 78～84.

[36] 曹代勇, 李小明,魏迎春,等. 构造煤与原生结构煤的热解成烃特征研究[J]. 煤田地质与勘探, 2005, 33 (4): 39～41.

Cao Daiyong, Li Xiaoming, Wei Yingchun, et al. Study on pyrogenation hydrocarbon generation character of deformed coal and undeformed coal[J]. Coal Geology & Exploration, 2005, 33 (4): 39～41.

[37] 琚宜文, 林红,李小诗,等. 煤岩构造变形与动力变质作用[J]. 地学前缘, 2009, 16 (1): 158～166.

Ju Yiwen, Lin Hong, Li Xiaoshi, et al. Tectonic deformation and dynamic metamorphism of coal[J]. Earth Science Frontiers, 2009, 16 (1): 158～166.
