唐山沿海地区地面沉降渗流固结耦合模拟研究

李铎; 刘洋; 方晓峰

doi:10.13544/j.cnki.jeg.2015.01.015

唐山沿海地区地面沉降渗流固结耦合模拟研究

doi: 10.13544/j.cnki.jeg.2015.01.015

李铎^1,2,
刘洋¹,
方晓峰¹

1.
石家庄经济学院石家庄 050031;
2.
河北省水资源可持续利用与开发重点实验室石家庄 050031

基金项目:

国家973计划项目(编号: 2010CB428805), 河北省水资源可持续利用与开发重点实验室项目(编号:W1007)资助

详细信息

作者简介:
李铎(1963-),男,博士,教授,从事地质工程方面研究. Email: Liduo556688@126.com

中图分类号: P642.26
计量
- 文章访问数: 2879
- HTML全文浏览量: 236
- PDF下载量: 633
- 被引次数: 0
出版历程
- 收稿日期: 2014-06-04
- 修回日期: 2014-12-28
- 刊出日期: 2015-02-25

SIMULATION OF LAND SUBSIDENCE IN COASTAL AREAS OF TANGSHAN WITH A SEEPAGE-CONSOLIDATION COUPLING MODEL

1.
Shijiazhuang University of Economics, Shijiazhuang 050031;
2.
Hebei Province Key Laboratory of Sustained Utilization and Development of Water Resources, Shijiazhuang 050031

摘要

摘要: 唐山沿海地区经济在迅速发展,沿海地区城市化规模在扩大,地下水开采量增大,地面沉降加剧.文中分析了唐山沿海地区的水文地质条件,概化为3个含水层、3个弱透水层,共6个压缩层.建立了三维地下水流和垂向一维压缩完全耦合模型.采用25a的观测资料校正模型,计算值与实测值拟合较好,模型具有较高的仿真性和适用性.预测了10a末的地面沉降;当地下水以现有开采量开采时,沉降中心累计达1192.3mm, 10a沉降352.3mm,沉降速率为35.23mma-1;当地下水的开采量在现有开采量的基础上增加10%时,沉降中心累计达1260.8mm, 10a沉降420.8mm,沉降速率为42.08mma-1; 当地下水的开采量在现有开采量的基础上减小10%时,沉降中心累计达1088.7mm, 10a沉降247.9mm,沉降速率为24.79mma-1.增大10%的地下水开采量, 10a地面沉降量增加68.5mm;减少10%的地下水开采量, 10a地面沉降量减少104.4mm.因此,控制地下水开采量是控制地面沉降的有效方法.
- 唐山 /
- 地面沉降 /
- 耦合模型 /
- 释水系数
Abstract: Accompanying with the rapid economic growth and urbanization expansion of the coastal areas of Tangshan, the quantity of groundwater exploitation has increased and land subsidence has aggravated. We analyze the hydrogeology condition in this region, and generalizes it into six compressed layers including three aquifers and three aquitards. A fully coupling model of three-dimensional groundwater flow and vertical one-dimensional compression is constructed. The simulation data, derived from the model calibrated with a 25 years observational data, are fitted well with the measured values, which verifies the model validity. According to our prediction, subsidence amount in subsidence center will be accumulatively up to 1192.3mm after 10 years. The subsidence over ten years will reach 352.3mm and the average subsidence rate will attain to 35.23mma-1 under present groundwater exploitation. If the amount of groundwater extraction increases 10%on the basis of existing mining quantity, the subsidence amount in subsidence center will achieve 1260.8mm. The subsidence amount in ten years will grow up to 420.8mm and the average subsidence rate will be 42.08mma-1.If reducing the groundwater extraction in 10%based on the existing mining quantity, at subsidence center the subsidence amount will accumulate to 1088.7mm. Subsidence amount in ten years will reach 247.9mm and the average subsidence rate will be 24.79mma-1. Subsidence amount over ten years will increase 68.5mm if the groundwater exploitation extends 10%, and it will decrease 104.4mm if the groundwater extraction reduces 10%.In summary, limiting the groundwater withdrawal is an effective method to control the land subsidence.
- Tangshan /
- Land subsidence /
- Coupling model /
- Coefficient of storage

HTML全文

参考文献(1)

Bravo R,Rogers J R,Cleveland T G. 1991. New three dimensional finite difference model of groundwater flow and land subsidence in the Houston area[A]//Johnson A I. Land Subsidence, Proceedings of the Fourth International Sysposium on Land Subsidence[C]. USA Houston: IAHS Publ, 15～26.

Chen C X,Pei S P. 2001. Study on groundwater exploitation-land subsidence model[J]. Hydrogeology and Engineering Geology, 28 (2): 5～8.

Cui X D. 1998. Application and development of MODFLOW and IDP in digital calculation of land subsidence in Tianjin[J]. The Chinese Journal of Geological Hazard and Control, 9 (2): 122～128.

Cui Y L,Shao J L,Xie Z H. 2003. A MODFLOW-based land subsidence model in Beijing city[J]. Geotechnical Investigation & Surveying,(5): 19～22.

Dong S G,Liu B W,Tang Z H. 2010. Numerical simulation of land subsidence of Taiyuan City[J]. Water Resources Protection, 26 (6): 19～22, 36.

Gambolat G,Ricceri G,Bertoni W. 1991. Numerical analysis of land subsidence at Ravenna due to water withdrawal and gas removal[A]//Johnson A I. Land Subsidence, Proceedings of the Fourth International Sysposium on Land Subsidence[C]. USA Houston: IAHS Publ, 199～128.

Guo Z R,Qu H L,Cui X D, et al. 1998. Study of numerical simulation of land subsidence in Tianjin[J]. Acta Geoscientia Sinica, 19 (4): 415～422.

Li W Y,Cui Y L,Su C, et al. 2012. An integrated numerical groundwater and land subsidence model of Tianjin[J]. Journal of Jilin University(Earth Science Edition), 42 (3): 805～813.

Luo Z J,Zeng F,Li Y. 2009. Study on three-dimensional full coupling model of groundwater exploitation and land-subsidence control[J]. Journal of Jilin University(Earth Science Edition), 39 (6): 1080～1086.

Tian B Z,Tao Z G,Li C C. 2011. Scientific computing and forecasting to land subsidence in coastal region of Tangshan[J]. Metal Mine,(5): 101～105.

Wei J H,Cui Y L,Shao J L, et al. 2000. 3D-finite element method simulation of groundwater and land subsidence in Jining City[J]. Journal of Changchun University of Science and Technology, 30 (4): 376～380.

Zhang H B,Jiang X Q,Guo R R. 1998. Land subsidence controlling in Tangshan along the Bohai Sea[J]. The Chinese Journal of Geological Hazard and Control, 9 (2): 161～166.

Zhang Y,Xue Y Q. 2002. Present sitution and prospect on the mathematical model of land subsidence due to pumping[J]. The Chinese Journal of Geological Hazard and Control, 13 (2): 1～6, 24.

Zheng X X,Wu Q,Hou Y S. 2002. Advances and trends in research on urban land subsidence[J]. Geological Review, 48 (6): 612～618.

陈崇希,裴顺平. 2001. 地下水开采——地面沉降模型研究. 水文地质工程地质, 28 (2): 5～8.

崔小东. 1998. MODFLOW和IDP在天津地面沉降数值计算中的应用与开发[J]. 中国地质灾害与防治学报, 9 (2): 122～128.

崔亚莉,邵景力,谢振华. 2003. 基于MODFLOW的地面沉降模型研究——以北京市区为例[J]. 工程勘察,(5): 19～22.

董少刚,刘白薇,唐仲华. 2010. 太原市地面沉降数值模拟[J]. 水资源保护, 26 (6): 19～22, 36.

郭占荣,曲焕林,崔小东,等. 1998. 天津市地面沉降数值模拟研究[J]. 地球学报, 19 (4): 415～422.

李文运,崔亚莉,苏晨,等. 2012. 天津市地下水流-地面沉降耦合模型[J]. 吉林大学学报(地球科学版), 42 (3): 805～813.

骆祖江,曾峰,李颖. 2009. 地下水开采与地面沉降控制三维全耦合模型研究[J]. 吉林大学学报(地球科学版), 39 (6): 1080～1086.

田宝柱,陶志刚,李昌存. 2011. 唐山沿海地区地面沉降科学计算与预测[J]. 金属矿山,(5): 101～105.

魏加华,崔亚莉,邵景力,等. 2000. 济宁市地下水与地面沉降三维有限元模拟[J]. 长春科技大学学报, 30 (4): 376～380.

张洪波,姜先桥,郭润瑞. 1998. 唐山沿海地面沉降防治研究[J]. 中国地质灾害与防治学报, 9 (2): 161～166.

张云,薛禹群. 2002. 抽水地面沉降数学模型的研究现状与展望[J]. 中国地质灾害与防治学报, 13 (2): 1～6, 24.

郑铣鑫,武强,侯艳声,等. 2002. 城市地面沉降研究进展及其发展趋势[J]. 地质论评, 48 (6): 612～618.
