施斌, 顾凯, 魏广庆, 吴静红, 张诚成. 2018: 地面沉降钻孔全断面分布式光纤监测技术. 工程地质学报, 26(2): 356-364. DOI: 10.13544/j.cnki.jeg.2018-104
    引用本文: 施斌, 顾凯, 魏广庆, 吴静红, 张诚成. 2018: 地面沉降钻孔全断面分布式光纤监测技术. 工程地质学报, 26(2): 356-364. DOI: 10.13544/j.cnki.jeg.2018-104
    SHI Bin, GU Kai, WEI Guangqing, WU Jinghong, ZHANG Chengcheng. 2018: FULL SECTION MONITORING OF LAND SUBSIDENCE BOREHOLE USING DISTRIBUTED FIBER OPTIC SENSING TECHNIQUES. JOURNAL OF ENGINEERING GEOLOGY, 26(2): 356-364. DOI: 10.13544/j.cnki.jeg.2018-104
    Citation: SHI Bin, GU Kai, WEI Guangqing, WU Jinghong, ZHANG Chengcheng. 2018: FULL SECTION MONITORING OF LAND SUBSIDENCE BOREHOLE USING DISTRIBUTED FIBER OPTIC SENSING TECHNIQUES. JOURNAL OF ENGINEERING GEOLOGY, 26(2): 356-364. DOI: 10.13544/j.cnki.jeg.2018-104

    地面沉降钻孔全断面分布式光纤监测技术

    FULL SECTION MONITORING OF LAND SUBSIDENCE BOREHOLE USING DISTRIBUTED FIBER OPTIC SENSING TECHNIQUES

    • 摘要: 本文介绍了一种钻孔全断面分布式光纤监测技术,可以获得地面沉降过程中多场多参量数据,实现钻孔全断面的精细化监测。阐述了钻孔全断面分布式光纤监测技术的概念,并重点介绍了该技术涉及的传感光缆和传感器选择、钻孔回填材料、光缆-土的耦合性评价和光缆及传感器植入方法等关键技术。在此基础上,构建了钻孔全断面光纤监测系统。最后,结合苏州盛泽地面沉降光纤监测案例,介绍了钻孔全断面光纤监测过程和技术特点。



      Abstract: This paper introduces a full section monitoring of land subsidence borehole using distributed fiber optic sensing(DFOS)techniques, which can obtain data on multi-fields and multi-parameters and provide delicate monitoring of land subsidence. The concept of full section monitoring of borehole using DFOS is firstly introduced. The key techniques on the application of this method include the selections of cables and sensors, the backfill materials, the coupling of cables and soils and the installation of cables and sensors in boreholes. A system frame of the full section monitoring of borehole with DFOS is built. Finally, the whole process of full section monitoring with DFOS and its features are illustrated with a case in Shengze Town, Suzhou.



    /
