隧道锚承载机制及承载力探究

王东英; 尹小涛; 汤华; 邓琴

doi:10.13544/j.cnki.jeg.2018129

隧道锚承载机制及承载力探究

doi: 10.13544/j.cnki.jeg.2018129

1.
中国科学院武汉岩土力学研究所, 岩土力学与工程国家重点试验室武汉 430071;
2.
中国科学院大学北京 100049

基金项目:

国家自然科学基金（51778609，41202226）资助

详细信息

作者简介:
王东英(1991-),女,博士生,主要从事隧道锚承载机制探究方面的研究工作.Email:wangdongying910309@163.com

中图分类号: U45
计量
- 文章访问数: 1627
- HTML全文浏览量: 324
- PDF下载量: 46
- 被引次数: 0
出版历程
- 收稿日期: 2018-05-31
- 修回日期: 2018-07-30
- 刊出日期: 2018-10-31

THE BEARING MECHANICS AND CAPACITY OF TUNNEL-TYPE ANCHORAGE

1.
State Key Laboratory of Geo-mechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071;
2.
University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 隧道锚的承载性能是隧道锚设计和工程应用需要解决的基本科学问题。隧道锚是底部大、上部小、呈倒塞体形的锚体结构，这一几何特征使得荷载作用下锚-岩界面产生附加应力。为探究不同加载阶段隧道锚承载部位和承载力的差异，通过分析各阶段附加应力变化情况建立不同加载阶段隧道锚承载力的表达式，并通过某大桥隧道锚现场缩尺模型试验对所推导公式进行实例验证。发现：隧道锚的承载阶段包括初始阶段、弹性阶段和塑性阶段3部分，隧道锚的初始承载力取决于锚碇体自重，峰值承载力则与隧道锚的破坏形态、附加应力大小直接相关。某大桥隧道锚沿锚-岩界面破坏，其初始承载力为1540 MN，是设计荷载的7倍；峰值承载力为3080 MN，是设计荷载的14倍。现场缩尺试验揭露的隧道锚临界承载力和极限承载力分别为设计荷载的9倍和13倍。以上结果表明：（1）不同加载阶段，隧道锚-岩体联合承载力的部位、岩体参与抗拔的范围、夹持锚碇体的程度均不相同；（2）隧道锚承载力的阶段性由锚-岩界面附加应力的变化引起；（3）建立的承载力估值公式与现场试验吻合性较好，可用于指导隧道锚设计。
- 隧道锚 /
- 承载性能 /
- 附加应力 /
- 阶段性特征
Abstract: The study on the bearing behavior of tunnel-type anchorage is the one of the basic scientific questions in the design and application of this type anchorage. Tunnel-type anchorages look like inverted-shape structures with bigger bottom and smaller top. This geometrical characteristic may be the main reason that the additional stress could initiate on the interface of anchor and rock under the main cable load. In order to study the difference of bearing capacity of tunnel-type anchorage in different load stage, the formulas of bearing capacities of anchorage are built with the analysis of the change law of additional stress. And these formulas are verified by the results of field model test. We find that:the load stages of tunnel-type anchorage can be classified as original stage, elastic stage and plastic stage. And the value of initial bearing capacity of tunnel-type anchorage relies on the gravity of the anchor while the ultimate capacity depending on the failure modes and additional stress. Besides, the failure surface of the object anchorage happens on the interface of the anchor and rock. And the initial bearing capacity of the support project is 1540MN,seven times higher than design load. The ultimate bearing capacity reaches to 3080MN,fourteen times higher than design load. While the results obtained from the field model test are 9 and 13 times higher than design load respectively. The results tell us that the bearing position, the range of rock taking part in the different stage and the degree of rock holding the anchor are different in different load stage. Moreover, the stage characteristics of tunnel-type anchorage capacity are closely relevant to the additional stress. And the geological characteristic of tunnel-type anchorage improves the bearing capacity tremendously. Last but not least, the estimation formulas for the bearing capacity is agree with the results of model test and can be applied to guide the design of tunnel-type anchorage.
- Tunnel-type anchorage /
- Bearing behavior /
- Additional stress /
- Characteristic of load stage

HTML全文

参考文献(1)

Hu B,Zeng Q B,Rao D,et al. 2007. Study of deformation law and failure mechanism of anchorage-surrounding rock system under tensile-shear complex stresses-Taking super-large suspension bridge on Baling river for example[J]. Chinese Journal of Rock Mechanics and Engineering,26(4):712-719.
Huang M S,Wang X J,Wu J B,et al. 2011. Unified approach to estimate ultimate bearing capacity of uplift piles with enlarged base[J]. Chinese Journal of Geotechnical Engineering,33(1):63-69.
Jiang N. 2014. Research on bearing mechanism of tunnel anchorage of railway suspension bridge and its calculation method[D]. Chengdu:Southwest Jiaotong University.
Jiang Y Z,Wang R H,Zhu J B,et al. 2016. Geo-mechanical model test on global stability for Wujiagang bridge tunnel-type anchorages[J]. Chinese Journal of Rock Mechanics and Engineering,35 (S2):4103-4113.
Jin Y J,He M C,Wang S R,et al. 2006. Study on the anchoring mechanism of pre-stressed anchor cable with dispersive pressure suitable for soft-rock slope reinforcing[J]. China Civil Engineering Journal,39(4):63-67.
Tang H,Xiong X R,Wu Z J,et al. 2015. Deformation law and failure mechanism of anchorage-surrounding rock system of Puli extre-large bridge[J]. Journal of Shanghai Jiaotong University,49(7):961-967.
Tang H,Xiong X R,Wu Z J,et al. 2015. Laboratory model test study of pull-out mechanism of tunnel anchorage[J]. Journal of Shanghai Jiaotong University,49(7):936-939.
Xiao B Z,Wu X C,Peng C Q. 2005. Stability of the anchorage wall rock of tunnel for Chongqing Egongyan bridge[J]. Chinese Journal of Rock Mechanics and Engineering,24 (S2):5591-5597.
Yang Z P,Liu S L,Ke W,et al. 2017. Influence of the size of tunnel anchorage on bearing behavior and its failure mechanism[J]. Chinese Journal of Underground Space and Engineering,13(5):1235-1241.
Zhang Q H,Li Y J,Yu M W,et al. 2017. Preliminary study of pullout mechanisms and computational model of pull out force for rocks surrounding tunnel-type anchorage[J]. Rock and Soil Mechanics,38(3):810-820.
Zhu J B,Wu A Q,Huang Z J,et al. 2006. Pulling test of anchorage model of Siduhe suspension bridge[J]. Journal of Yangtze Rover Scientific Research Institute,23(4):51-55.
胡波,曾钱帮,饶旦,等. 2007. 锚碇-围岩系统在拉剪复合应力条件下的变形规律及破坏机制研究-以坝陵河特大岩锚悬索桥为例[J]. 岩石力学工程学报,26(4):712-719.
黄茂松,王向军,吴江斌,等. 2011. 不同桩长扩底抗拔桩极限承载力的统一计算模式[J]. 岩土工程学报,33(1):63-69.
江南. 2014. 铁路悬索桥隧道式锚碇承载机理及计算方法研究[D]. 成都:西南交通大学.
蒋昱州,王瑞红,朱杰兵,等. 2016. 伍家岗大桥隧道锚三维地质力学模型试验研究[J]. 岩石力学与工程学报, 35(S2):4103-4113.
金永军,何满潮,王树仁,等. 2006. 适用于软岩边坡加固的压力分散型预应力锚索锚固机理研究[J]. 土木工程学报,39(4):63-67.
汤华,熊晓荣,吴振君,等. 2015a. 隧道锚抗拔作用机理的室内模型试验[J]. 上海交通大学学报,49 (7):935-939, 945.
汤华,熊晓荣,邓琴,等. 2015b. 普立特大桥隧道式锚碇围岩系统的变形规律及破坏机制[J]. 上海交通大学学报,49(7):961-967.
肖本职,吴相超,彭朝全. 2005. 重庆鹅公岩大桥隧道锚碇围岩稳定性[J]. 岩石力学与工程学报, 24(增 2):5591-5597.
杨忠平,刘树林,柯炜,等. 2017. 隧道锚尺寸对其承载特性的影响及破坏机理[J]. 地下空间与工程学报,(5):1234-1241.
张奇华,李玉婕,余美万,等. 2017. 隧道锚围岩抗拔机制及抗拔力计算模式初步研究[J]. 岩土力学,38(3):810-820.
朱杰兵,邬爱清,黄正加,等. 2006. 四渡河特大悬索桥隧道锚模型拉拔试验研究[J]. 长江科学院院报,23(4):51-55.
