地下水渗流荧光单孔测速流场畸变系数的试验研究

蔡征龙 孟永东 李方方 缪蕊 田斌 田爽岑

蔡征龙, 孟永东, 李方方, 等. 2023. 地下水渗流荧光单孔测速流场畸变系数的试验研究[J]. 工程地质学报, 31(5): 1711-1718. doi: 10.13544/j.cnki.jeg.2021-0259
引用本文: 蔡征龙, 孟永东, 李方方, 等. 2023. 地下水渗流荧光单孔测速流场畸变系数的试验研究[J]. 工程地质学报, 31(5): 1711-1718. doi: 10.13544/j.cnki.jeg.2021-0259
Cai Zhenglong, Meng Yongdong, Li Fangfang, et al. 2023. Experimental study on distortion coefficient of single-hole fluorescence photoelectric method for groundwater seepage monitoring[J]. Journal of Engineering Geology, 31(5): 1711-1718. doi: 10.13544/j.cnki.jeg.2021-0259
Citation: Cai Zhenglong, Meng Yongdong, Li Fangfang, et al. 2023. Experimental study on distortion coefficient of single-hole fluorescence photoelectric method for groundwater seepage monitoring[J]. Journal of Engineering Geology, 31(5): 1711-1718. doi: 10.13544/j.cnki.jeg.2021-0259

地下水渗流荧光单孔测速流场畸变系数的试验研究

doi: 10.13544/j.cnki.jeg.2021-0259
基金项目:

国家重点研发计划项目 2017YFC1501100

国家自然科学基金重点项目 51939004

详细信息
    作者简介:

    蔡征龙(1988-),男,博士,讲师,主要从事岩土工程稳定性与滑坡地质灾害治理方面的研究. E-mail: caizhenglo@163.com

    通讯作者:

    孟永东(1976-),男,博士,教授,主要从事岩土工程稳定性与滑坡地质灾害治理方面的研究. E-mail: mengydedit@126.com

  • 中图分类号: P641.2

EXPERIMENTAL STUDY ON DISTORTION COEFFICIENT OF SINGLE-HOLE FLUORESCENCE PHOTOELECTRIC METHOD FOR GROUNDWATER SEEPAGE MONITORING

Funds:

the National Key Research and Development Plan 2017YFC1501100

National Natural Science Foundation of China 51939004

  • 摘要: 荧光光电法作为地下水单孔渗流监测的重要手段,而流场畸变系数合理取值是荧光单孔渗流监测的关键。为有效提高荧光光电法在地下水单孔渗流测速的准确率,开发设计了荧光单孔地下渗流模型的监测试验系统,分析研究不同渗流条件下的流场畸变系数。首先,依据单孔稀释模型推导了荧光光电法流场畸变系数的数学表达式;然后根据自制光电监测装置,开发设计了荧光单孔渗流监测系统的试验装置;最后通过研究荧光剂稀释过程中的光电强度变化来研究不同含水层、侧孔孔径和开孔率条件下流场畸变系数的变化规律,确定不同监测条件下流场畸变系数的取值范围。试验结果表明:流场畸变系数随渗透流速和滤管开孔率的增加而增加,随测孔孔径的增大而减小,且影响因子重要性为含水层>测孔孔径>开孔率。以上研究成果可为荧光单孔地下水渗流监测的实际工程应用提供有益借鉴。
  • 图  1  流线畸变现象(董海洲等,2000)

    Figure  1.  The distortion phenomenon of flow line (Dong et al.,2000)

    图  2  流速调节系统平面布置图

    Figure  2.  Layout plane of flow speed control system

    图  3  试验箱装置图

    Figure  3.  Diagram of test units

    图  4  滤管开孔情况

    Figure  4.  The porosity of filter tube

    图  5  清水试验时光电流随时间变化情况

    Figure  5.  The variation of photocurrent with time in clean water test

    图  6  不同开孔率条件下流场畸变系数随渗透流速的变化

    Figure  6.  The change law of distortion coefficient with seepage velocity under different open porosity

    图  7  不同渗透流速条件下流场畸变系数随测孔孔径的变化

    Figure  7.  The change law of distortion coefficient with drilling diameter under different seepage velocity

    图  8  不同测孔孔径条件下流场畸变系数随开孔率的变化

    Figure  8.  The change law of distortion coefficient with drilling diameter under different open porosity

    图  9  畸变系数变化云图

    a. 渗透流速 vs 测孔孔径; b. 开孔率 vs 测孔孔径

    Figure  9.  Cloud diagram of change of distortion coefficient: (a) seepage velocity vs. drilling diameter,(b)open porosity vs drilling diameter
