基于COMSOL Multiphysics的降雨型滑坡临界降雨阈值计算模型研究——以新疆新源县喀拉海依苏滑坡隐患体为例

开迪尔丁·吾拉木 张紫昭 张艳阳 朱建华 陈伟楠

开迪尔丁·吾拉木, 张紫昭, 张艳阳, 等. 2023. 基于COMSOL Multiphysics的降雨型滑坡临界降雨阈值计算模型研究———以新疆新源县喀拉海依苏滑坡隐患体为例[J]. 工程地质学报, 31(4): 1364-1374. doi: 10.13544/j.cnki.jeg.2023-0206
引用本文: 开迪尔丁·吾拉木, 张紫昭, 张艳阳, 等. 2023. 基于COMSOL Multiphysics的降雨型滑坡临界降雨阈值计算模型研究———以新疆新源县喀拉海依苏滑坡隐患体为例[J]. 工程地质学报, 31(4): 1364-1374. doi: 10.13544/j.cnki.jeg.2023-0206
Kaidierding Wulamu, Zhang Zizhao, Zhang Yanyang, et al. 2023. COMSOL Multiphysic based calculation model of critical rainfall threshold for rainfall-induced landslide-A case study of Karahayisu Landslide in Xinyuan County, Xinjiang[J]. Journal of Engineering Geology, 31(4): 1364-1374. doi: 10.13544/j.cnki.jeg.2023-0206
Citation: Kaidierding Wulamu, Zhang Zizhao, Zhang Yanyang, et al. 2023. COMSOL Multiphysic based calculation model of critical rainfall threshold for rainfall-induced landslide-A case study of Karahayisu Landslide in Xinyuan County, Xinjiang[J]. Journal of Engineering Geology, 31(4): 1364-1374. doi: 10.13544/j.cnki.jeg.2023-0206

基于COMSOL Multiphysics的降雨型滑坡临界降雨阈值计算模型研究——以新疆新源县喀拉海依苏滑坡隐患体为例

doi: 10.13544/j.cnki.jeg.2023-0206
基金项目:

国家自然科学基金项目 41967036

新疆维吾尔自治区重点研发项目 2021B03004-1

详细信息
    作者简介:

    开迪尔丁·吾拉木(1998-),男,硕士生,主要从事地质灾害发生机理与监测预警相关研究. E-mail: ks071231@163.com

    通讯作者:

    张紫昭(1981-),男,博士,教授,博士生导师,主要从事地质灾害和地质环境方面的科研与教学工作. E-mail: 253569481@qq.com

  • 中图分类号: P642.22

COMSOL MULTIPHYSIC BASED CALCULATION MODEL OF CRITICAL RAINFALL THRESHOLD FOR RAINFALL-INDUCED LANDSLIDE—A CASE STUDY OF KARAHAYISU LANDSLIDE IN XINYUAN COUNTY, XINJIANG

Funds:

the National Natural Science Foundation of China 41967036

the Key R & D Project of Xinjiang Uygur Autonomous Region 2021B03004-1

  • 摘要: 本文以新源县喀拉海依苏滑坡隐患体为研究案例,采用COMSOL Multiphysics数值模拟有限元软件,建立了基于非饱和渗流理论与Mohr-Coulomb准则的滑坡稳定性计算模型。根据数值模拟结果得到研究区滑坡体原始应力分布与初始孔隙压力的分布情况、在降雨入渗条件下的内部应力、有效塑性应变、塑性区、含水率、潜在滑移面等的分布情况,并计算得到滑坡体在降雨入渗条件下的安全系数。根据模型计算,滑坡体在不同降雨入渗工况下的安全系数随降雨量的增大而减小,滑坡体在连续降雨5天的临界阈值为218.82 mm,根据安全系数的变化可得到滑坡体临界降雨阈值。该论文提供了一种强度折减安全系数计算降雨型黄土滑坡降雨阈值的数值模拟方法,研究结果为西北地区降雨型黄土滑坡失稳破坏的临界降雨阈值研究提供了一种有效的研究手段。
