考虑应力历史和应力水平影响的土体压缩模量计算方法

曹宇清; 吴永; 安向勇; 苏晓学; 樊习英; 巩天真

doi:10.13544/j.cnki.jeg.yt2019395

考虑应力历史和应力水平影响的土体压缩模量计算方法

doi: 10.13544/j.cnki.jeg.yt2019395

曹宇清^①,,
吴永^{②, ③, ,},
安向勇^①,
苏晓学^①,
樊习英^①,
巩天真^④

①.
国网山西省电力公司经济技术研究院太原 030006
②.
交通运输部公路科学研究院北京 100088
③.
北京新桥技术发展有限公司北京 100088
④.
山西科汇工程质量检测有限公司太原 030013

基金项目:

国网山西省电力公司科技项目 SGSXJYOOPSJS1800005

详细信息

作者简介:
曹宇清(1968-), 男, 学士, 从事工程管理工作.Email:543354191@qq.com

通讯作者:
吴永(1986-), 男, 硕士, 主要从事桥梁与隧道检测工作.Email:liulin@imech.ac.cn

中图分类号: P642.3
计量
- 文章访问数: 3500
- HTML全文浏览量: 1422
- PDF下载量: 77
- 被引次数: 0
出版历程
- 收稿日期: 2019-03-18
- 修回日期: 2019-06-20
- 刊出日期: 2019-08-25

CALCULATION METHOD FOR OEDOMETRIC MODULUS OF SOIL WITH EFFECTS OF STRESS HISTORY AND STRESS LEVEL

CAO Yuqing^{①
,},
WU Yong^{②, ③
, ,},
AN Xiangyong^①,
SU Xiaoxue^①,
FAN Xiying^①,
GONG Tianzhen^④

①.
State Grid Shanxi Economic and Technology Research Institute of Electric Power Company, Taiyuan 030006
②.
Research Institute of Highway Ministry of Transport, Beijing 100088
③.
Beijing Xinqiao Technology Development Co., Ltd., Beijing 100088
④.
Shanxi Kehui Engineering Quality Inspection Co., Ltd., Taiyuan 030013

Funds:

the Science and Technology Projects of State Grid Corporation of China SGSXJYOOPSJS1800005

摘要

摘要: 为了考虑应力历史对地基沉降变形的影响，本文基于单对数函数，引入压缩曲线在单对数空间上曲率最小时所对应的竖向应力（简称特征应力），建立了能够描述正常固结黏土、超固结黏土和砂土的压缩线表达式。然后，基于该表达式提出完全侧限条件下的压缩模量计算式，并分析了特征应力和压缩指数对压缩模量的影响规律。最后，通过与室内试验结果和实际工程中地基变形进行对比，验证了本文所提方法的合理性。
- 压缩模量 /
- 应力历史 /
- 应力水平 /
- 地基沉降
Abstract: This paper presents a united expression of the compression lines of normal compressed clay, overconsolidated clay and sand by introducing a special vertical stress in single logarithmic coordinates. And then, based on the new expression and the concept of compression modulus, we obtain a calculation method for the compressive modulus of soil. Evolutionary laws of compressive modulus are presented and analyzed with the special vertical stress and compression index changing, respectively. Finally, comparisons with the test results and foundation settlement in engineering case indicate the rationality of this calculation method.
- Oedometric modulus /
- Stress history /
- Stress level /
- Foundation settlement

HTML全文

图 1 超固结土压缩线示意图

Figure 1. Compression line of overconsolidated soil

下载: 全尺寸图片幻灯片

图 2 压缩模量随特征应力的演化规律

Figure 2. Evolution law of oedometric modulus as special vertical stress changes

下载: 全尺寸图片幻灯片

图 3 压缩模量随压缩指数的演化规律

Figure 3. Evolution law of oedometric modulus as compression index changes

下载: 全尺寸图片幻灯片

图 4 压缩模量的计算结果和试验结果的比较

a.粉土; b.粉土; c.粉土黏土; d.粉土夹粉质黏土

Figure 4. Comparison between calculation results and test results of oedometric modulus

下载: 全尺寸图片幻灯片

表 1 试验土的基本物理指标

Table 1. Physical indexes of soil

土的种类	含水率/%	干密度/ (g·cm^-3)	内摩擦角/(°)	黏聚力/kPa	初始孔隙比e₀
①粉土	17	1.42	18.7	9.5	1.22
②粉土	23.8	1.45	21.8	10.4	1.30
③粉质黏土	24.5	1.45	16.5	22.5	1.32
④粉土夹粉质黏土	25.0	1.46	22.7	11.5	1.31

下载: 导出CSV

表 2 材料参数

Table 2. Material parameters

土的种类	压缩指数	σ_vc/kPa
①粉土	0.14	220
②粉土	0.14	190
③粉质黏土	0.15	220
④粉土夹粉质黏土	0.1	160

下载: 导出CSV

表 3 材料参数

Table 3. Material parameters

土的种类	压缩指数	初始孔隙比
②粉土黏土	0.133/ln10	0.96
③淤泥质粉质黏土	0.21/ln10	1.2
④淤泥质黏土	0.38/ln10	1.47
⑤粉质黏土	0.38/ln10	0.94

下载: 导出CSV

表 4 本文计算过程

Table 4. Calculation procedure

土层	σ_szi/kPa	H_i/cm	σ_vc/kPa	σ_zi/kPa	Δe	ΔS/cm
②	29	160	58	84	0.039	3.2
③	119	520	209	68.3	0.017	4.1
④	202	500	303	45.6	0.014	2.89
⑤	292	500	292	44.6	0.012	3.13

下载: 导出CSV

参考文献(33)

Chen F J, Ma J L, Zhu L, et al. 2012. Settlement calculation of pile foundation in deep-soft soil considering depth effect of compression modulus[J]. Rock and Soil Mechanics, 33 (S2):167-172. http://cn.bing.com/academic/profile?id=31c5ccea2416ba7550eb9dbbb372da34&encoded=0&v=paper_preview&mkt=zh-cn

Deng W L, Zhou Z M. 1996. A calculating method for soils modulus of compressibility (Es)[J]. Industrial Construction, 26(10):34-36.

Hou X L, Tan X H, Liu Z Y, et al. 2017. Compressive indices of cohesive soil and relation to degree of saturation[J]. Journal of Engineering Geology, 25(5):1336-1343. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gcdzxb201705021

Jiang A L, Zhao C F, Gao D Z. 2003. Mathematical model method of determining preconsolidation pressure[J]. Rock and Soil Mechanics, 24(2):292-295. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ytlx200302031

Jose B T, Sridharan A, Abraham B M. 1989. Log-log method for determination of preconsolidation pressure[J]. Geotechnical Testing, 12(3):230-237. doi: 10.1520/GTJ10974J

Liu Q Y, Liang J G, Feng H P. 2018. The settlement and deformation of foundation under high stress[J]. Journal of Water Resources and Architectural Engineering, 16(5):111-115. http://d.old.wanfangdata.com.cn/Periodical/fsjs201805021

Luo T, Liu L, Yao Y P. 2017. Description of critical state for sands considering particle crushing[J]. Chinese Journal of Geotechnical Engineering, 39(4):592-600. http://d.old.wanfangdata.com.cn/Periodical/ytgcxb201704002

Mei G X, Zai J M, Zhao W B. 2003. A simplified calculation method of oedometric modulus of soil and its application[J]. Rock and Soil Mechanics, 24(6):1057-1064. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ytlx200306041

Meng X L, Zhao X Y, Fan Z H, et al. 2017. Experimental study of compressive modulus of metroshield generation zone in kunming cumulosols[J]. Journal of Engineering Geology, 25(6):1617-1623.

Ministry of Housing and Urban-Rural Development of the People's Republic of China, 2011. Code for design of building foundation(GB 50007-2011)[S]. Beijing: China Architecture & Building Press.

Qian J H, Yin Z Z. 1996. Geotechnical principles and calculations[M]. Beijing:China Water & Power Press.

Sridharan A, Abraham B M, Jose B T. 1991. Improved technique for estimation of preconsolidation pressure[J]. Géotechnique, 41(2):263-268. doi: 10.1680/geot.1991.41.2.263

Wang Z L, Zheng M X, Li Y C. 2005. Research on mathematic model method for calculating pre-consolidation pressure and its application[J]. Rock and Soil Mechanics, 26(10):1587-1590. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ytlx200510012

Xu G P, Fu B Y, Zhang Z G, et al. 2013. Janbu tangent modulus method for settlement and determination of parameters[J]. Chinese Journal of Geotechnical Engineering, 35 (S2):804-808. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=8494417

Yang A W, Zhang Z D, Li X W, et al. 2017. Microscopic structure evaluation parameters of soft dredger fill in stage of safe operation hyperplasia with preconsolidation effect[J]. Journal of Engineering Geology, 25(2):284-291.

Yang G H. 2006. Nonlinear settlement computation of the soil foundation with the undisturbed soil tangent modulus method[J]. Chinese Journal of Geotechnical Engineering, 28(11):1927-1931. http://cn.bing.com/academic/profile?id=c6fdf25a5f19afebdf55de0ee47d257e&encoded=0&v=paper_preview&mkt=zh-cn

Yao Y P, Liu L, Luo T, et al. 2019. Unified hardening(UH)model for clays and sands[J]. Computers and Geotechnics, 110:326-343. doi: 10.1016/j.compgeo.2019.02.024

Yao Y P, Liu L, Luo T. 2018. A constitutive model for granular soils[J]. Science China Technological Sciences, 61(10):1546-1555. doi: 10.1007/s11431-017-9205-8

陈福江, 马建林, 朱林, 等. 2012.考虑压缩模量深度效应的深厚软土桩基沉降计算[J].岩土力学, 33 (S2):167-172. http://cdmd.cnki.com.cn/Article/CDMD-10613-1016166612.htm

邓文龙, 周正茂. 1996.土的压缩模量E_s的一种取值方法[J].工业建筑, 26(10):34-36. doi: 10.3321/j.issn:1000-8993.1996.10.012

侯晓亮, 谭晓慧, 刘泽勇, 等. 2017.黏性土压缩指标及其与饱和度的关系[J].工程地质学报, 25(5):1336-1343. http://www.gcdz.org/CN/abstract/abstract12553.shtml

姜安龙, 赵春风, 高大钊. 2003.确定先期固结压力的数学模型法[J].岩土力学, 24(2):292-295. doi: 10.3969/j.issn.1000-7598.2003.02.031

刘启源, 梁金国, 冯怀平. 2018.考虑压缩模量随应力水平变化的地基沉降变形研究[J].水利与建筑工程学报, 16(5):111-115. doi: 10.3969/j.issn.1672-1144.2018.05.020

罗汀, 刘林, 姚仰平. 2017.考虑颗粒破碎的砂土临界状态特性描述[J].岩土工程学报, 39(4):592-600. http://d.old.wanfangdata.com.cn/Periodical/ytgcxb201704002

梅国雄, 宰金珉, 赵维炳. 2003.土体侧限压缩模量简易计算方法及其应用[J].岩土力学, 24(6):1057-1064. doi: 10.3969/j.issn.1000-7598.2003.06.041

孟祥连, 赵晓彦, 范智浩, 等. 2017.昆明泥炭质土地铁盾构等代层压缩模量试验研究[J].工程地质学报, 25(6):1617-1623. http://www.gcdz.org/CN/abstract/abstract12624.shtml

钱家欢, 殷宗泽. 1996.土工原理与计算[M].北京:中国水利水电出版社.

王志亮, 郑明新, 李永池. 2005.求前期固结应力的数学模型研究及应用[J].岩土力学, 26(10):1587-1590. doi: 10.3969/j.issn.1000-7598.2005.10.012

徐国平, 付佰勇, 张志刚, 等. 2013. Janbu切线模量沉降计算方法及参数取值初探[J].岩土工程学报, 35 (S2):804-808. http://d.old.wanfangdata.com.cn/Conference/8494417

杨爱武, 张振东, 李潇雯, 等. 2017.考虑前期固结影响的吹填软土安全运营阶段微结构演化特征[J].工程地质学报, 25(2):284-291. http://www.gcdz.org/CN/article/downloadArticleFile.do?attachType=PDF&id=12350

杨光华. 2006.地基非线性沉降计算的原状土切线模量法[J].岩土工程学报, 28(11):1927-1931. doi: 10.3321/j.issn:1000-4548.2006.11.002

姚仰平, 刘林, 罗汀. 2016.砂土的UH模型[J].岩土工程学报, 38(12):2147-2153. doi: 10.11779/CJGE201612002

中华人民共和国住房和城乡建设部. 2011.建筑地基基础设计规范(GB 50007-2011)[S].北京: 中国建筑工业出版社.
