地下洞室岩体变形模量的尺寸效应研究

张占荣

地下洞室岩体变形模量的尺寸效应研究

张占荣

中铁第四勘察设计院集团有限公司武汉 430063

基金项目:

十一五国家科技支撑计划(2008BAB29B01-1)

详细信息

作者简介:
张占荣,工程地质专业.Email: zzrwh@126.com

中图分类号: TU452
计量
- 文章访问数: 4077
- HTML全文浏览量: 151
- PDF下载量: 965
- 被引次数: 0
出版历程
- 收稿日期: 2009-10-02
- 修回日期: 2011-08-16
- 刊出日期: 2011-10-25

SIZE EFFECT TO ROCK MASS DEFORMATION MODULUS FOR UNDERGROUND HOUSE

ZHANG Zhanrong

China Railway Siyuan Survey and Design Group Co. ,Ltd.,Wuhan 430063

摘要

摘要: 变形参数是岩体工程变形计算、稳定性评价的前提,岩体变形参数的合理取值一直是岩土工程界关注的热点和难点之一。由于岩体力学参数存在随研究尺度不同而变化的特性,被称之为岩体力学参数的尺寸效应,因此由室内试验获取的岩石力学参数,甚至现场试验获取的岩体力学参数,均代表不了岩体工程尺度实际的力学特性,不能直接用于工程实际。为获取能够直接应用于工程实际的岩体力学参数,有必要对岩体力学参数随尺度的变化规律及产生机理展开系统研究。本文结合工程实例,通过多尺度方法研究了裂隙岩体变形参数的尺寸效应,采用室内试验、现场承压板试验、波速测试、数值模拟、位移反演分析等不同尺度的研究方法,获取了不同尺度的岩体力学参数。研究表明随着岩体尺寸的增加,岩体变形模量呈明显的降低趋势,由回归分析得到了岩体变形参数与尺度之间的拟合关系式,当岩体尺寸大于30m后,岩体变形模量减小的趋势逐渐趋于稳定,由此确定了该工程岩体宏观变形模量及REV尺度。在此基础上,对裂隙岩体变形模量尺寸效应的产生机理进行探讨,表明岩体变形参数尺寸效应的产生机理主要是由于不同尺度岩体所涵盖的裂隙尺度不同所造成,节理岩体的REV尺度约为典型结构面迹长的3倍左右。基于多种试验方法成果与数理统计方法相结合研究岩体变形参数的尺寸效应是一种新的尝试,为该工程岩体力学参数的合理取值提供了依据,并可为类似工程提供有益借鉴。
- 岩体 /
- 力学参数 /
- 变形模量 /
- 尺寸效应 /
- 多尺度方法 /
- 统计分析
Abstract: Deformation parameters of engineering rock mass are important necessary precondition for deformation calculation and stability analysis.So the reasonable selection on the deformation parameters is a focus and difficulty in geotechnical engineering.Because of size effect,the mechanical parameters would change with the research size of rock mass.Mechanical parameters from laboratory test,even from in-situ test can't exactly represent the characteristics of the engineering rock mass.In order to get mechanical parameters of the engineering rock mass that can be applied to practical engineering directly,the size effect of rock mass parameters and its mechanism of production need to be systemically studied.The size effect of rock mass deformation parameters is studied by multi-scale methods combined with specific engineering project.Deformation modulus with different sizes of rock mass are got from the experiments of laboratory test,in-situ plate load test,wave velocity test,numerical simulation and displacement back analysis.It is found that the rock mass deformation modulus decreases significantly as the rock mass size increases.When the tested rock mass size is larger than 30m,the deformation modulus of rock mass tends to be stable.Equations between deformation modulus and rock mass size are got with regression analysis.Then the macro-mechanical parameters and the REV scale are obtained.Finally,the mechanism of the size effect to rock mass deformation modulus is discussed.It shows the structural planes with different size within rock mass are the intrinsic cause for the mechanism.The REV scale of jointed rock mass is about 3 times of the length of the main structure.When the size is larger than the REV scale,the deformation modulus of rock mass would became a stable value.It is a new attempt to survey the macro parameters of rock mass by combination of multi-scale methods and statistics theory.The findings presented in this paper can provide a useful reference to the parameter determination of rock mass in geotechnique engineering and other similar projects.
- Rock mass /
- Mechanical parameters /
- Deformation modulus /
- Size effect /
- Multi-scale method /
- Statistical analysis

HTML全文

参考文献(1)

[1] 符文熹, 尚岳全,孙红月等.岩体变形参数渐变取值模型及工程应用[J].工程地质学报, 2002, 10 (2): 198~203. Fu Wenxi,Shang Yuequan,Sun Hongyue,et al.Application of progressively changing rock mass deformation parameters to rock mass engineering.Journal of Engineering Geology, 2002, 10 (2): 198~203.

[2] 周火明, 盛谦,邬爱清.三峡工程永久船闸边坡岩体宏观力学参数的尺寸效应研究[J].岩石力学与工程学报, 2001, 20 (5): 661~664. Zhou Huoming,Sheng Qian,Wu Aiqing.Size effect analysis on macro-mechanics parameters for the rock masses of the Tgp shiplock slope.Chinese Journal of Rock Mechanics and Engineering, 2001, 20 (5): 661~664.

[3] 盛谦, 杨启贵,陈胜宏.节理岩体宏观力学参数的计算机模拟试验[J].地下空间, 1999, 19 (5): 482~487. Sheng Qian,Yang Qigui,Chen Shenghong.Study on numerical simulation tests of macro-mechanical parameters of fractured rock mass.Underground Space, 1999, 19 (5): 482~487.

[4] 郭志华. 层状岩体宏观力学参数的计算机模拟试验 .武汉: 中国科学院武汉岩土力学研究所, 2005. Guo Zhihua.Numerical Simulation Tests on Macro Mechanic Parameters of Layered Rock Mass.Wuhan: Institute of Rock and Soil Mechanics,Chinese Academy of Sciences, 2005.

[5] Pinto A,Da Cunha.Scale Effects in Rock Masses[M].Rotterdam: AA Balkema Publishers, 1990.

[6] 周济芳, 李建林,王瑞红.关于卸荷岩体尺寸效应的数值仿真研究[J].四川水利, 2008,(4): 69~71. Zhou Jifang,Li Jianlin,Wang Ruihong.Study on numerical simulation of the size effects of unloading rock mass.Sichuan Water Resources, 2008,(4): 69~71.

[7] Lianyang Zhang,HH Einstein.Using RQD to estimate the deformation modulus of rock masses[J].International Journal of Rock Mechanics and Mining Sciences, 2004, 41 (2): 337~341.

[8] 周创兵, 於三大.论岩体表征单元体积REV——岩体力学参数取值的一个基本问题[J].工程地质学报, 1999, 7 (4): 332~336. Zhou Chuangbing,Yu Sanda.Representative elementary volume REV—A fundamental problem for selecting the mechanical parameters of jointed rockmass.Journal of Engineering Geology, 1999, 7 (4): 332~336.

[9] 尤明庆, 邹友峰.关于岩石非均质性与强度尺寸效应的讨论[J].岩石力学与工程学报, 2000, 19 (3): 391~395. You Mingqing,Zou Youfeng.Discussion on heterogeneity of rock material and size effect on Specimen strength.Chinese Journal of Rock Mechanics and Engineering, 2000, 19 (3): 391~395.

[10] 刘宝琛, 张家生.岩石抗压强度的尺寸效应[J].岩石力学与工程学报, 1998, 17 (6): 611~614. Liu Baochen,Zhang Jiasheng.A study of size effect for compression strength of rock.Chinese Journal of Rock Mechanics and Engineering, 1998, 17 (6): 611~614.

[11] 张志刚, 乔春生.改进的节理岩体变形模量经验确定方法及其工程应用[J].工程地质学报, 2006, 14 (2): 233~238. Zhang Zhigang,Qiao Chunsheng.Improved empirical method for determination of deformation modulus of jointed rock masses and its application in engineering.Journal of Engineering Geology, 2006, 14 (2): 233~238.

[12] Hill R.Elastic properties of reinforced solids: Some theoretical principles[J].Journal of the Mechanics and Physics of Solids, 1963, 11 (5): 357~372.

[13] 向文飞, 周创兵.裂隙岩体表征单元体研究进展[J].岩石力学与工程学报, 2005, 24 (S2): 5686~5692. Xiang Wenfei,Zhou Chuangbing.The advances in investigation of representative elementary volume for fractured rock mass.Chinese Journal of Rock Mechanics and Engineering, 2005, 24 (S2): 5658~5692.

[14] 中国水电顾问集团成都勘测设计研究院. 大岗山水电站岩石力学试验研究报告 ,2005. HydroChina Chengdu Engineering Corporation.Rock Mechanical Tests Study Report of Dagangshan Hydropower Station in Sichuan Province,2005.

[15] 张占荣, 盛谦,杨艳霜,等.基于现场试验的岩体变形模量尺寸效应研究[J].岩土力学, 2010, 31 (9): 2875~2881. Zhang Zhanrong,Sheng Qian,Yang Yanshuang,et al.The study of the size effect of rock mass deformation modulus based on the in-situ test.Rock and Soil Mechanics, 2010, 31 (9): 2875~2881.

[16] 张占荣. 裂隙岩体变形特性研究 .武汉: 中国科学院武汉岩土力学研究所, 2010. Zhang Zhanrong.Study on Deformation Properties of Fractured Rock Mass.Wuhan: Institute of Rock and Soil Mechanics,Chinese Academy of Sciences, 2010.

[17] 中国水电顾问集团成都勘测设计研究院. 四川大渡河大岗山水电站可行性研究报告 ,2006. HydroChina Chengdu Engineering Corporation.Feasibility Study Report of Dagangshan Hydropower Station in Sichuan Province,2006.

[18] Oda M A.Method for evaluating the representative elementary volume based on joint survey of rock masses[J].Canadian Geotechnical Journal,1988, 25 (3):440~447
