宝鸡地区典型黄土剖面钻孔岩芯工程地质特性研究

谭成轩; 孙炜锋; 张春山; 吴树仁; 石菊松; 李滨; 王涛

宝鸡地区典型黄土剖面钻孔岩芯工程地质特性研究

谭成轩^1,2,
孙炜锋^1,2,
张春山^1,2,
吴树仁^1,2,
石菊松^1,2,
李滨^1,2,
王涛^1,2

1.
中国地质科学院地质力学研究所北京 100081;
2.
国土资源部新构造运动与地质灾害重点实验室北京 100081

基金项目:

国家十一五科技支撑课题(2006BAC04B05),中国地质调查局项目(1212010640401)和国家科技支撑计划课题(2008BAK47B04)

详细信息

作者简介:
谭成轩,主要从事区域地壳稳定性评价、工程地质和地质灾害研究.Email: tanchengxuan@tom.com

中图分类号: P642
计量
- 文章访问数: 5476
- HTML全文浏览量: 204
- PDF下载量: 1233
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-21
- 修回日期: 2011-02-28
- 刊出日期: 2011-10-25

ENGINEERING GEOLOGICAL FEATURES FROM BOREHOLE CORES FOR TYPICAL LOESS SECTION IN BAOJI REGION OF LOESS PLATEAU

1.
Institute of Geomechanics,Chinese Academy of Geological Sciences,Beijing 100081;
2.
Key Laboratory of Neotectonic Movement & Geohazard,Beijing 100081

摘要

摘要: 在野外详细调查的基础上,对宝鸡市陈仓区贾村塬典型黄土剖面进行了原状全程取芯钻探工程,并开展了室内系统物理力学参数和物质组成测试分析,以探讨滑坡形成机制。系统的测试分析表明:密度和孔隙比之间成负相关关系; 液限和塑限之间呈正相关关系,两者曲线波动的规律基本一致; 压缩模量和压缩系数成负相关关系; 内聚力和内摩擦角呈负相关的关系,但数据波动较大。典型黄土剖面黄土与古土壤颗粒组成、碳酸盐含量及主要黏土矿物分析表明: 0.075~0.010mm粗粉土粒含量和碳酸盐含量呈正相关关系,二者与内聚力呈负相关关系,而与内摩擦角呈正相关关系; 0.002mm胶粒成分主要为伊利石蒙脱石混层矿物,其次为伊利石和高岭石,并与内聚力呈正相关关系,而与内摩擦角呈负相关关系。
- 宝鸡地区 /
- 贾村塬典型黄土剖面 /
- 物理力学参数 /
- 物质组成
Abstract: A new complete loess profile has been found in Baoji region of the Loess Plateau in recent years.Based on this profile,this paper presents a study of the features of loess engineering geology.The loess is about 200m thick and formed from Holocene epoch to Lower Pleistocene epoch.The study is based on a detailed field investigation of typical loess section at Jiacun Terrace in Chenchang of Baoji region.Borehole drilling in the typical loess layer was conducted.Approximately undisturbed cores were obtained for the entire borehole depth.Subsequently,a systematic laboratory tests were carried out for the physical and mechanical parameters and material formation of the cores.The data was for the analysis of landslide mechanism and prevention.The test results show that 1)there is an inverse correlation between density and porosity ratio,2)there is a positive correlation between liquid limit and plastic limit along with the borehole depth, 3)there is an inverse correlation between modulus of compression and compressibility factor,and 4)there is an inverse correlation between internal cohension and internal friction angle with large variation range along the borehole depth.The analyses on the grain size analysis,carbonate content and major clay minerals of the typical loess show that a)there is a positive correlation between the 0.075mm to 0.010mm grain contents and the carbonate content,b)the grain and carbonate contents have an inverse correlation with the internal cohesion and a positive correlation with the internal friction angle,and c)there is a positive correlation of the less than 0.002mm colloid particle contents with the mixed-layer mineral of illite and montmorillonite,illite,kaolinite and other major clay minerals,and d)the less than 0.002mm colloid particle contents also have a positive correlation with the internal cohesion and an inverse correlation with the internal friction angle.The systematic test results presented in this paper will have an important significance to increase the scientific degree and reliability of loess landslide risk assessment.
- Baoji region /
- Jiacun terrace /
- Loess /
- Physical-mechanical parameters

HTML全文

参考文献(1)

[1] 刘东生,孙继敏,吴文祥.中国黄土研究的历史、现状和未来;一次事实与故事相结合的讨论.第四纪研究, 2001, 21 (3): 185~207. Liu Tungsheng,Sun Jimin,Wu Wenxiang. Past,present and future of the Chinese loess research: a discussion on the reality of facts and myth.Quaternary Sciences, 2001, 21 (3): 185~207.

[2] 刘东生,等.黄土与环境.北京:科学出版社, 1985. Liu Tungsheng, et al. Loess and environments.Beijing: Science Press, 1985.

[3] 孙建中.黄土学(上篇).香港:香港考古学会出版, 2005. Sun Jianzhong.Loessology(Part one).HongKong:HongKong Archaeological Society, 2005.

[4] 刘东生,等.黄土的物质成分和结构.北京:科学出版社, 1966. Liu Tungsheng, et al.Composition and texture of loess.Beijing: Science Press, 1966.

[5] 丁仲礼,刘东生.中国黄土研究新进展(一):黄土地层.第四纪研究, 1989, 9 (1): 24~35. Ding Zhongli,Liu Tungsheng.Progresses of loess research in China(part Ⅰ): loesstratigraphy.Quaternary Sciences, 1989, 9 (1): 24~35.

[6] 丁仲礼,刘东生,刘秀铭,等.250万年以来的37个气候旋回.科学通报, 1989, 34 (19): 1494~1496. Ding Zhongli,Liu Tungsheng,Liu Xiuming, et al.The 37 climatic cycles in the past 250×10⁴ years.Chinese Science Bulletin, 1989, 34 (19): 1494~1496.

[7] 孙建中,袁维红,李慧琴."第四纪"一词之存废及其下界之浅见.第四纪研究, 2005, 25 (6): 670~675. Sun Jianzhong,Yuan Weihong,Li Huiqin."Quaternary"should be reserved or discard,and where is its lower boundary？Quaternary Sciences, 2005, 25 (6): 670~675.

[8] 雷祥义.黄土显微结构类型与物理力学性质指标之间的关系.地质学报, 1989,(2): 182~190. Lei Xiangyi.The relation between loess micro-texture types and physical-mechanical parameters.Acta Geologica Sinica, 1989,(2): 182~190.

[9] 岳应利.黄土工程力学性质的变化及控制因素.陕西师范大学学报(自然科学版), 2002, 30 (1): 111~115. Yue Yingli.Change of engineering mechanics character of loess and controlling factors.Journal of Shaanxi Normal University(Natural Science Edition), 2002, 30 (1): 111~115.

[10] 赖天文,何斌.黄土物理力学性质指标的变异性及相关性分析.兰州铁道学院学报(自然科学版), 2003, 22 (6): 110~112. Lai Tianwen,He Bin.The variability and correlativity of physical and mechanical parameter of loess.Journal of Lanzhou Railway University(Natural Sciences), 2003, 22 (6): 110~112.

[11] 岳应利.黄土高原西部黄土工程物理性质及其成因.中国沙漠, 2004, 24 (6): 680~684. Yue Yingli.Engineering physics property of loess and its causes in western loess plateau.Journal of Desert Research, 2004, 24 (6): 680~684.

[12] 高国瑞,韩爱民.论中国区域性土的分布和岩土性质的形成.岩土工程学报, 2005, 27 (5): 511~515. Gao Guorui,Han Aimin.Distribution of regional soils in China and formation of their special geotechnical properties.Chinese Journal of Geotechnical Engineering, 2005, 27 (5): 511~515.

[13] 谢定义.黄土力学特性与应用研究的过去、现在与未来.地下空间, 1999,(4): 273~284. Xie Dingyi.The past,present and future of the research on mechanical characteristics and application of loess.Underground Space, 1999,(4): 273~284.

[14] 谢定义.试论我国黄土力学研究中的若干新趋向.岩土工程学报, 2001, 23 (1): 3~12. Xie Dingyi.Exploration of some new tendencies in research of loess soil mechanics.Chinese Journal of Geotechnical Engineering, 2001, 23 (1): 3~12.

[15] 谢定义,齐吉琳.土结构性及其定量化参数研究的新途径.岩土工程学报, 1999,(6): 651~656. Xie Dingyi,Qi Jilin.Soil structure characteristics and new approach in research on its quantitative parameter.Chinese Journal of Geotechnical Engineering, 1999,(6): 651~656.

[16] 张永双,曲永新.万家寨引黄工程大梁段砂黄土的工程地质特性研究.岩土工程学报, 2004, 26 (2): 229~233. Zhang Yongshuang,Qu Yongxin.Engineering properties of sand-loess from the Daliang region along the Wanjiazhai water diversion project.Chinese Journal of Geotechnical Engineering, 2004, 26 (2): 229~233.

[17] 张永双,曲永新.黄土高原马兰黄土黏土矿物的定量研究.地质论评, 2004, 50 (5): 530~537. Zhang Yongshuang,Qu Yongxin.Quantitative research on clay mineral composition of the Malan loess from the loess plateau in China.Geological Review, 2004, 50 (5): 530~537.

[18] 张永双,曲永新.陕北晋西砂黄土的胶结物与胶结作用的研究.工程地质学报, 2005, 11 (1): 18~28. Zhang Yongshuang,Qu Yongxin.Cements of sand loess and their cementation in north Shaanxi and west Shanxi.Journal of Engineering Geology, 2005, 11 (1): 18~28.

[19] 王永焱,林在贯.中国黄土的结构特征与物理力学性质.北京:科学出版社, 1990. Wang Yongyan,Lin Zaiguan.Structural features and physical and mechanical properties of Chinese loess.Beijing: Science Press, 1990.

[20] 段汝文,王峻,李兰.黄土的物理力学指标与黄土易损性分析研究.西北地震学报, 1997, 19 (3): 81~85. Duan Ruwen,Wang Jun,Li Lan.On relationship between physical mechanical indices and vulnerability of loess.Northwestern Seismological Journal, 1997, 19 (3): 81~85.

[21] 段汝文.陇西黄土的强度特性.西北地震学报, 1993, 15 (1): 67~71. Duan Ruwen.The strength character of loess in longxi area of GanSu.North Western Seismological Journal, 1993, 15 (1): 67~71.

[22] 关文章.湿陷性黄土工程性能新篇.西安:西安交通大学出版社, 1992. Guan Wenzhang.New development on engineering features of collapsible loess.Xi'an:Xi'an Jiao Tong University Press, 1992.

[23] 高国瑞.中国黄土微结构.科学通报, 1980, 25 (20): 945~948. Gao Guorui.Chinese loess microstructure.Chinese Science.Bulletin, 1980, 25 (20): 945~948.

[24] 高国瑞.黄土显微结构分类与湿陷性.中国科学(A辑), 1980, 23 (12): 1203~1208. Gao Guorui.Classification of microstructure and collapsibility of loess.Science in China(Series A), 1980, 23 (12): 1203~1208.

[25] 高国瑞.黄土湿陷变形的结构理论.岩土工程学报, 1990, 12 : 1~9. Gao Guorui.Structure theory of loess soil deformation.Chinese Journal of Geotechnical Engineering, 1990, 12 : 1~9.

[26] 沈珠江.关于黄土力学的研究途径 .中加非饱和土学术研讨会论文集 ,武汉, 1994, 153~60. Shen Zhujiang.A approach to loess mechanics research.Proceedings of the seminar on unsaturated soil in Sino-Canada,Wuhuan, 1994, 153~60.

[27] 骆亚生.中国典型黄土动力特性及其参数的试验分析.西安:西安理工大学出版社, 2000. Luo Yashang.Experiment analysis on typical loess dynamic features and its parameters in China.Xi'an:Xi'an Technology University Publishing House, 2000.

[28] 李云峰.黄土渗透性与孔隙性研究.北京:地质出版社, 1994. Li Yunfeng.A study on penetrability and porosity of loess.Beijing:Geological Publishing House, 1994.

[29] 赵景波,童心刚,张晓龙等.陕西长安县杨湾剖面黄土含水条件研究.陕西师范大学学报(自然科学版), 2002, 30 (3): 109~113. Zho Jingbo,Tong Xingang,Zhang Xiaolong et al.Moisture content of loess profile at Yangwan village in Chang'an county of Shaanxi province.Journal of Shaanxi Normal University(Natural Science Edition), 2002, 30 (3): 109~113.

[30] Wang Jianguo.A Micromechanical Structural Analysis of Collapse Deformation of Loess. 7th International Conference on Expansive Soils, 1992.

[31] 武孟元,王险峰.绳索取芯钻探施工技术.水科学与工程技术, 2006,(3): 5~6. Wu Mengyuan,Wang Xianfeag.Construction technology of line core drilling.Water Sciences and Engineering Technology, 2006,(3): 5~6.

[32] 朱永宜.KZ型单动双管取心钻具的研制与应用.石油钻探技术, 2006, 34 (3): 19~22. Zhu Yongyi.Development and application of Kz single rotary and double tube core barrel.Petroleum Drilling Techniques, 2006, 34 (3): 19~22.

[33] 文宝萍.黄土地区典型滑坡预测预报及减灾对策研究.北京:地质出版社, 1997. Wen Baoping.Typical loess landslides forecast and countermeasures.Beijing:Geological Publishing House, 1997.

[34] 吴玮江.甘肃省东部滑坡发育规律初探.兰州大学学报, 1992.28(增刊): 124~130. Wu Weijiang.An approach to developing law in the eastern part of Gansu province.Journal of Lanzhou University, 1992. 28 (supp.): 124~130.

[35] 王恭先.甘肃省永靖县黄茨滑坡的滑动机理与临滑预报.灾害学, 1997, 12 (3): 23~27.。

Wang Gongxian.Sliding mechanism and prediction of critical sliding of Huangci landslide in Yongjing county,GanSu porovince.Journal of Catastrophology, 1997, 12 (3): 23~27.

[36] 王家鼎.强震作用下低角度黄土斜坡滑移的复合机理研究.岩土工程学报, 2001, 23 (4): 446~450. Wang Jiading.A study on compound mechanism of earthquake-related sliding displacements on gently inclined loess slope.Chinese Journal of Geotechnical Engineering, 2001, 23 (4): 446~450.

[37] 曲永新,张永双,覃祖淼.三趾马红土与西北黄土高原滑坡.工程地质学报, 1999, 7 (3): 257~265. Qu Yongxin,Zhang Yongshuang,Qin Zumiao.Hipparion laterite and landslide hazards on loess plateau of northwestern China.Journal of Engineering Geology, 1999, 7 (3): 257~265.

[38] 孙波.陕北黄土滑坡地貌演变分析.铁道工程学报, 1999,(1): 67~71. Sun Bo.Analysis on development of landform for loess landslide in northern region of shaanxi province.Journal of Railway Engineering Society, 1999,(1): 67~71.

[39] 王维升,万鑫.浅议黄土滑坡的分布规律及形成条件.灾害学, 2001, 16 (2): 82~86. Wang Weisheng,Wan Xin.Distribution regularity and forming condition of loess landslide.Journal of Catastrophology, 2001, 16 (2): 82~86.

[40] 王德耀,杜忠潮,张满社.陕西省泾阳南塬崩塌、滑坡地质灾害及成因分析.水土保持通报, 2004, 24 (4): 34~37. Wang Deyao,Du Zhongchao,Zhang Manshe.Geological hazard of cliff collapse,landslide and their occurrence in southern Jingyang county of Shaanxi province.Bulletin of Soil and Water Conservation, 2004, 24 (4): 34~37.

[41] 文宝萍,王思敬,王恩志等.黄土-红层接触面滑坡的变形特征.地质学报, 2005, 79(1): 144. Wen Baoping,Wang Sijing,Wang Enzhi et al.Deformation feature of the contactsurfacein landslide between loess and red clay.Acta Geologica Sinica, 2005, 79(1): 144.

[42] 王志荣,王念秦.黄土滑坡研究现状综述.中国水土保持, 2004,(11): 16~18. Wang Zhirong Wang Nianqin.A summary of present study on loess landslides.Soil and Water Conservation in China, 2004,(11): 16~18.

[43] 崔中兴,杨作栋.黄土地区滑坡的机理分析及防治对策.水土保持通报, 1994, 14 (6): 48~52. Cui Zhongxing,Yang Zuodong.Analysis on deformation mechanism of landslide and its prevention strategies in loess plateau.Bulletin of Soil and Water Conservation, 1994, 14 (6): 48~52.

[44] Skempton A.W.Residual Strength of clays in landslide,folded strata and the laboratory.Geotechnique,London, 1985, 35 (1): 3~181.
