高密度电法在地铁岩溶勘察中的应用

蔡晶晶; 阎长虹; 王宁; 邵勇; 郑军; 汤志刚

高密度电法在地铁岩溶勘察中的应用

1.
南京大学地球科学与工程学院南京 210093;
2.
南京地铁科技咨询公司南京 210012

详细信息

作者简介:
蔡晶晶,地质工程专业.Email: aoxiang888366@sina.com

中图分类号: P642.25
计量
- 文章访问数: 3773
- HTML全文浏览量: 219
- PDF下载量: 991
- 被引次数: 0
出版历程
- 收稿日期: 2011-02-10
- 修回日期: 2011-07-24
- 刊出日期: 2011-12-25

APPLICATION OF HIGH-DENSITY RESISTIVITY METHOD TO KARST INVESTIGATION OF METRO ENGINEERING

1.
School of Earth Sciences and Engineering,Nanjing University,Nanjing 210093;
2.
Nanjing Metro Research and Development Consulting Co. Ltd.,Nanjing 210012

摘要

摘要: 南京地铁3号线将穿越岗谷地和岩溶区,是建设施工过程中的几大难题之一。经过初步勘查,发现其中某段有多处溶洞。该段地处闹市区,交通流量大,建筑物密集,地下管线多,地质条件较为复杂。为了查明研究区岩溶发育情况,结合地质构造条件,经综合比选,采用高密度电法进行岩溶勘察,测量方法选择温纳剖面法。测量过程中将部分电极勘察点布设于沥青或混凝土路面上,接地条件相对较差,采用常规数据处理方法(数据反演),与实际钻探结果误差较大,不宜使用。因此在测量中采用改进电极与地面耦合条件以及加大供电电压的方法,提高电流穿透力,同时对所测数据直接绘制成等值线图。根据等值线图中低电阻率分布特征推断岩溶发育情况,其结果与钻探结果较为吻合,取得了较好效果。经与现场工程地质调查和钻孔资料对比分析,查明沿线岩溶空间分布。研究结果表明物探方法具有多解性,在开始物探工作之前,应对研究区地质和构造条件进行野外调查,对岩溶发育特征进行地质分析,以便更好的指导物探布线和数据解译工作; 当接地条件较差时,可以采取堆土、洒水等方法解决电极耦合问题; 对于数据反演解译存在误差时,可直接利用视电阻率等值线图进行解译,推测溶洞分布。
- 高密度电法 /
- 南京地铁 /
- 岩溶勘察 /
- 温纳 /
- 等值线法
Abstract: The No.3 line of Nanjing Metro would cross a valley and karst area,which is one of the several major geotechnical problems during the construction.A preliminary survey showed that there were many caves in the area.It's located in the downtown area where has heavy traffic and dense buildings,many underground pipelines and complicated geological conditions.In order to find out the karst development situation in a certain place for the engineering,the high-density resistivity method was used for karst prospecting after combination of geological structure and comprehensive election.The WN measurement was carried out.The electrical sense points are located on asphalt or cement concrete pavements.The condition of the sense contact to the ground surface was poor.So it had substantial errors in the back analysis process.For this reason,the electrode with ground coupling conditions were improved in the measurement.The power supply voltage was also increased to improve the current penetration.During testing,the isolines were rendered on the test data directly.According to the characteristics of low resistivity distribution from the isolines,the karst development situation was inferred.The results coincide with the drilling results relatively.The results were successful.After the contrast analysis between field engineering geological investigation and the borehole data,the spatial distribution of the karsts was identified.The results show that the geophysical method has multiple solutions.Before the geophysical work,a field investigation should be carried out for the geological and tectonic conditions in study area.Then geological analysis of the karst characteristics should be carried out in order to guide the work of geophysical wiring and data interpretation well.When the ground conditions are poor,the methods of piling soil up and watering can be undertaken to solve the problem of electrode coupling.To the existence of error of the back analysis,the isoline map of apparent resistivity can be used directly to infer the locations of karsts.
- High-density resistivity /
- Nanjing Metro /
- Karst investigation /
- WN /
- isoline method

HTML全文

参考文献(1)

[1] 邢崴崴, 阎长虹.南京市地铁工程环境地质评价[J].工程地质学报, 2004, 12 (3): 298~302. Xing Weiwei,Yan Changhong.Evaluation of environmental geology for Nanjing subway project, 2004, 12 (3): 298~302.

[2] 罗国煜,等. 城市环境岩土工程[M].南京: 南京大学出版社, 2000. Luo Guoyu,et al.Urban Environmental Geotechnology.Nanjing: Nanjing University Press, 2000.

[3] 李美梅. 高密度电阻率法正反演研究及应用 .北京:中国地质大学(北京), 2010, 44~51. Li Meimei.Research on Forward Modeling and Inversion.of Multi-electrode Resistivity Method.China University of Geosciences(Beijing), 2010, 44~51.

[4] 董浩斌, 王传雷.高密度电法的发展与应用[J].地学前缘, 2003, 10 (1): 171~176. Dong Haobin,Wang Chuanlei.Development and application of 2D resistivity imaging surveys.Earth Science Frontiers, 2003, 10 (1): 171~176.

[5] 刘金涛, 胡晓明.高密度电法勘探在岩溶查找中的应用[J].地质科技情报, 2003, 22 (2): 100~102. Liu Jintao,Hu Xiaoming.Application of the distributed multi-electrode resistivity maging method in finding the karst.Geological Science and Technology Information, 2003, 22 (2): 100~102.

[6] 李富, 刘树才,等.高密度电阻率法在工程勘察中的应用[J].工程地球物理学报, 2006, 3 (2): 119~124. Li Fu,Liu Shucai,et al.Application of high-density resistivity method in engineering prospecting.Chinese Journal of Engineering Geophysics, 2006, 3 (2): 119~124.

[7] 江玉乐, 康万福,等.高密度电法在岩溶勘察中的应用[J].成都理工大学学报, 2007, 34 (4): 452~455. Jiang Yule,Kang Wanfu,et al.Application of high density resistivity method to karst exploration.Journal of Chengdu University of Technology, 2007, 34 (4): 452~455.

[8] 周小仙, 钱荣毅.高密度电法在卵石覆盖区中的应用研究[J].工程勘察, 2009, 37 (11): 81~85. Zhou Xiaoxian,Qian Rongyi.Applied research on high-density resistivity tomography in cobble covered area.Geotechnical Investigation & Surveying, 2009, 37 (11): 81~85.

[9] 樊耀武, 王启军,等.高密度电阻率法在工程勘察中的应用[J].铁道工程学报, 2009, 131 (8): 31~33. Fan Yaowu,Wang Qijun,et al.Application of high-density resistivity method in engineering exploration.Journal of Railway Engineering Society, 2009, 131 (8): 31~33.

[10] 杨荣丰, 张可能,等.多种物探方法在湘潭城区活断裂探测中的应用[J].工程地质学报, 2006, 14 (6): 847~851. Yang Rongfeng,Zhang Keneng,et al.Exploration of fault zone in urban Xiangtan with self-potential frequency,high density resistivity and geological rader methods.Journal of Engineering Geology, 2006, 14 (6): 847~851.

[11] 铁道部第二勘测设计院. 岩溶工程地质[M].北京:中国铁道出版社, 1984, 15~19. Second Survey and Design Institute of Railways Ministry.Engineering Geology of Karst.China Railway Publishing House, 1984, 15~19.

[12] 阎长虹, 王玉英,等.压性构造对岩溶发育的控制作用——以贵州普定地区为例[J].地质论评, 2008, 54 (3): 343~347. Yan Changhong,Wang Yuying,et al.Compressive structure's control on the karst development.Geological Review, 2008, 54 (3): 343~347.
