基于BOTDR的地裂缝分布式光纤监测技术研究

卢毅; 施斌; 席均; 苏晶文; 姜月华; 李云峰

基于BOTDR的地裂缝分布式光纤监测技术研究

卢毅¹,
施斌^1, ,,
席均¹,
苏晶文²,
姜月华²,
李云峰²

1.
南京大学地球科学与工程学院南京 210093;
2.
南京地质矿产研究所南京 210016

基金项目:

国家重点基础研究发展计划（973计划）（2011CB710605）和国家自然科学基金重点项目（41230636）资助

详细信息

作者简介:
卢毅，主要从事环境岩土工程研究.Email：lynju@163.com

通讯作者:
施斌，教授，博士生导师，主要从事工程地质和环境岩土工程研究.Email：shibin@nju.edu.cn

中图分类号: P642.26;TP79
计量
- 文章访问数: 4121
- HTML全文浏览量: 251
- PDF下载量: 991
- 被引次数: 0
出版历程
- 收稿日期: 2013-01-20
- 修回日期: 2013-05-28
- 刊出日期: 2014-02-25

FIELD STUDY OF BOTDR-BASED DISTRIBUTED MONITORING TECHNOLOGY FOR GROUND FISSURES

1.
The School of Earth Sciences and Engineering, Nanjing University, Nanjing 210093;
2.
Nanjing Institute of Geology and Mineral Resources, Nanjing 210016

摘要

摘要: 地裂缝的监测是防治地裂缝危害的一项重要工作。本文采用基于BOTDR的分布式光纤感测技术对已有地裂缝和潜在地裂缝进行了分布式监测，详细介绍了BOTDR分布式光纤感测技术原理和地裂缝分布式监测方法，并以无锡杨墅里地裂缝作为监测点进行了现场试验研究。研究结果表明：基于BOTDR的分布式光纤感测技术可十分有效地对地裂缝的变形进行监测；采用定点布设的方法，可提高感测光纤的监测精度和量程，测量精度可以达到0.1mm； 2m长的定点间距，量程可达30mm；通过网格化铺设感测光缆，可对一定区域内的多条地裂缝进行监测；在同一方向上，不同点距的结合，可提高地裂缝监测的定位精度。
- 地裂缝 /
- BOTDR /
- 分布式监测 /
- 感测光纤
Abstract: The monitoring of ground fissures plays an important role in the prevention and control of the ground fissure hazard. In this paper, BOTDR-based distributed monitoring technology is used to monitor the development process of ground fissures. The principle of distributed optical fiber sensing technology and the distributed monitoring method are introduced. The field monitoring of ground fissures located in Wuxi is studied. The results show that BOTDR-based distributed monitoring technology can be effectively used to the deformation monitoring of ground fissures. Its monitoring accuracy and measuring range can be improved by the fixed-point layout of optical fiber. The monitoring accuracy can reach 0.1mm and the measuring range can raise 30mm. The multiple ground fissures within a certain area can be monitored by the gridded laying of optical fiber. The positioning accuracy of the ground fissure monitoring can be improved by setting up the different lengths between two fixed-points along the same direction.
- Ground fissures /
- BOTDR /
- Distributed monitoring /
- Sensing optical fiber
