汶川地震触发文家沟高速远程滑坡-碎屑流成因机理分析

王涛; 石菊松; 吴树仁; 张永双; 李滨; 辛鹏; 孙萍

汶川地震触发文家沟高速远程滑坡-碎屑流成因机理分析

国土资源部新构造运动与地质灾害重点实验室中国地质科学院地质力学研究所北京 100081

基金项目:

973计划项目课题专题(NO.2008CB425803):汶川地震重大次生山地灾害风险管理系统研究; 中国地质调查局项目(NO.1212010914025):龙门山及邻近构造带地震工程地质调查评价; 国家十一五科技支撑课题(NO.2006BAC04B05):地质灾害风险评估技术研究

详细信息

作者简介:
王涛,博士研究生,主要从事地质灾害研究,Email:wangtao820707@163.com

中图分类号: P65
计量
- 文章访问数: 5913
- HTML全文浏览量: 247
- PDF下载量: 2693
- 被引次数: 0
出版历程
- 刊出日期: 2010-10-15

FORMATION MECHANISM OF WENJIAGOU HIGH-SPEED AND LONG-RUNOUT DEBRIS AVALANCHE TRIGGERED BY WENCHUAN EARTHQUAKE

Key laboratory of Neotectonic Movement &|Geo-hazard,Ministry of Land and Resources,Institute of Geomechanics,Chinese Academy of Geological Sciences,Beijing 100081

摘要

摘要: 文家沟高速远程滑坡-碎屑流位于映秀北川断裂带与灌县安县断裂带夹持的文家沟向斜断块中,地震断裂的强烈活动引起的振动效应是形成滑坡的先决条件。滑坡源区顶端与文家沟沟口高差约1360m,突兀山体下临深切峡谷的地形使地震动荷载在山脊部位的放大效应显著,并直接导致坡体破坏; 滑坡源区的地震动加速度3分量峰值分别为aEW=2.4g,aNS=2.3g,aUP=1.2g。D2gn观雾山组石灰岩斜坡具有强度渐进式分层结构,坡体表层以下约50m内的结构相对松散的残坡积层~新鲜岩体上部无法抵抗地震纵横波的周期性拉压与剪切耦合作用,被切割成为初始滑体; 滑体在第八级台地边缘高位剪出后,在文家沟上游地区最高滑移速度约介于93m s-1~122m s-1之间。滑体上部的干碎屑流在两处路径转折端瞬间压缩沟谷内的圈闭气体,形成明显的气垫效应,滑体下部泥石流底层液化和颗粒有效动摩擦系数随剪切速度增大而减小的效应都是导致碎屑流体高速远程滑移的关键; 同时,碎屑物流通过程中还伴有明显的岸坡铲刮与翻越效应、以及树木摧削效应。汶川地震后截至2009年9月,降雨诱发碎屑堆积物形成多次泥石流,反映了地震地质灾害的链生性和长期性。
- 汶川地震 /
- 文家沟 /
- 高速远程 /
- 滑坡-碎屑流 /
- 成因机理
Abstract: The seismic geological context,morphology,formation mechanism and evolution of Wenjiagou high-speed and long-runout debris avalanche are introduced. The debris avalanche was located at Wenjiaogou syncline block between Yingxiu-Beichuan fault and Guanxian-Anxian fault of which severe activity provides precondition for the debris avalanche. It is 1360m high from the peak of debris avalanche source area to Wenjiagou valley mouth; seismic load shows remarkable amplification effect at the ridge due to the terrain of towering hill with deep valley at the foot,and directly results in the landslide. The peak values of ground motion acceleration in 3 directions in the ridge are aEW=2.4g,aNS=2.3g,aUP=1.2g(g: the acceleration of gravity). The Guanwushan formation(D2gn)limestone slope has layered structure with progressive strength. About 50m below the slope surface is loose structural Qel+dl~upper part of fresh rock,which is cut into initial landslide mass results from the tension-compression and shear coupling effect due to seismic P-wave and S-wave. The sliding mass shear out from edge of the 8th platform; the maximum traveling velocity of sliding mass is accelerated up to 93~122m s-1 in Wenjiagou valley upstream. Trapped air inside of the valley is compressed by upper part of landslide mass,the dry debris flow,at 2 turnings of Wenjiagou valley; distinct air cushion effect is generated. Besides,the bottom layer of debris flow is liquefied; effective dynamic friction coefficient is decreased with increasing of shearing velocity; all of these effects lead to the high-speed and long-runout traveling of debris flow. Simultaneously,the valley slope is scraped and crossed; the trees are cut as debris flow passes. After Wenchuan earthquake,up to Sept. 2009,rainfall has triggered several debris flows,which indicates the continuity and long-term nature of seismic geohazard.
- Wenchuan earthquake /
- Wenjiagou /
- High-speed and Long-runout /
- Debris avalanche /
- Formation mechanism

HTML全文

参考文献(1)

[1] 殷跃平.汶川八级地震滑坡特征分析
[J]. 工程地质学报, 2009,(1): 29~38.
Yin Yueping. Features of landslides triggered by the Wenchuan earthquake. Journal of Engineering Geology, 2009, 17 (1): 29~38.

[2] Highland,L.M. ,P. Bobrowsky,The Landslide Handbook—A Guide to Understanding Landslides. 2008,U.S. Geological Survey Circular 1325: Reston,Virginia. p. 129.

[3] 黄润秋,裴向军,李天斌.汶川地震触发大光包巨型滑坡基本特征及形成机理分析
[J]. 工程地质学报, 2008, 16 (6): 730~741.
Huang Runqiu,Pei Xiangjun,Li Tianbin. The basic characteristics and formation mechanism of Daguangbao large-scale landslide triggered by Wenchuan earthquake. Journal of Engineering Geology, 2008, 16 (6): 730~741.

[4] 许强,黄润秋. 5.12汶川大地震诱发大型崩滑灾害动力特征初探
[J]. 工程地质学报, 2008, 16 (6):721~729.
Xu Qiang,Hu Runqiu. Kinetics characteristics of large landslides triggered by May 12th Wenchuan earthquake. Journal of Engineering Geology, 2008, 16 (6): 721~729.

[5] Heim,A. ,Bergsturz und Menschenleben. Fretz und Wasmuth,Zu¨rich, 1932, 218.

[6] Kent,P.E. ,The transport mechanism in catastrophic rock falls. J. Geol, 1966,74: 79~83.

[7] Shreve,R.L. ,The Blackhawk landslide. Geol. Soc. Am. Spec. Pap. ,1968, 108: 1~47.

[8] Shreve,R.L. ,Leakage and fluidisation in air-layer lubricated avalanches. Geol. Soc. Am. Bull. ,1968b, 79:653~658.

[9] Voighta,B. ,J. Sousa,Lessons from Ontake-san: A comparative analysis of debris avalanche dynamics Engineering Geology, 1994, 38 (3~4): 261~297.

[10] Sassa,K. Access to the dynamics of landslides during earthquakes by a new cyclic loading high-speed ring shear apparatus. in 6th Int. Symp. Landslides. 1992. Christchurch: Balkema,Rotterdam.

[11] Davies,T.R.H. ,Spreading of rock avalanche debris by mechanical fluidization Rock Mechanics and Rock Engineering, 1982, 15 (1): 9~24.

[12] Campbell,C.S. ,P.W. Cleary,M. Hopkins,Large-scale landslide simulations: global deformation,velocities and basal friction. J. Geophys. Res. ,1995,100: 8267~8273.

[13] 胡广韬.滑坡动力学
[M]. 北京: 地质出版社,1995.
Hu Guangtao. Landslide Dynamics. Beijing: Geology Press,1995.

[14] 胡厚田,刘涌江,邢爱国,等. 高速远程滑坡流体动力学理论的研究
[M]. 成都: 西南交通大学出版社,2003.
Hu Houtian,Liu Yongjiang,Xing Aiguo,et al. Study on fluid dynamics theory of high-speed and long-runout landslide. Chengdu: Southwest Jiaotong University Press,2003.

[15] 程谦恭,彭建兵,胡广韬,等. 高速岩质滑坡动力学
[M]. 成都: 西南交通大学出版社,1999.
Cheng Qiangong,Peng Jianbing,Hu Guangtao,et al. High-speed rock landslide dynamics. Chengdu: Southwest Jiaotong University Press,1999.

[16] 熊传祥,龚晓南,王成华,高速滑坡临滑变形能突变模型的研究
[J]. 浙江大学学报(工学版), 2000, 34 (4): 443~447.
Xiong Chuanxiang,Gong Xiaonan,Wang Chenghua. A deformation energy catastrophic model of high-speed landslide before sliding. Journal of Zhejiang University(Engineering Science), 2000, 34 (4): 443~447.

[17] 肖盛燮,周小平,杨海清,等. 二维高速滑坡力学模型
[J]. 岩石力学与工程学报, 2006, 25 (3): 456~461.
Xiao Shengxie,Zhou Xiaoping,Yang Haiqing,et al. Two-dimensional mechanical model of high-speed landslides. Chinese Journal of Rock Mechanics and Engineering, 2006, 25 (3): 456~461.

[18] 刘涌江,胡厚田,白志勇. 大型高速滑坡体运动的空气动力学研究
[J]. 西南交通大学学报, 2002, 37 (1): 6~9.
Liu Yongjiang,Hu Houtian,Bai Zhiyong. Aerodynamic Effect of Large-Scale and High-Speed Landslide. Journal of Southwest Jiaotong University, 2002, 37 (1): 6~9.

[19] 赵晓彦,胡厚田,齐明柱. 云南头寨沟大型岩质高速滑坡碰撞模型试验
[J]. 自然灾害学报, 2003, 12 (3): 99~103.
Zhao Xiaoyan,Hu Houtian,Qi Mingzhu. Model experiment of high-speed collision of landslide rock masses in Touzhai Gully,Yunnan. Journal of Natural Disasters, 2003, 12 (3): 99~103.

[20] 殷跃平. 西藏波密易贡高速巨型滑坡特征及减灾研究
[J]. 水文地质工程地质, 2000,(4): 8~11.
Yin Yueping. Features and hazard mitigation of Yigong rapid huge landslide,Bomi,Tibet. Hydrogeology and engineering geology, 2000,(4): 8~11.

[21] 黄润秋,中国西部地区典型岩质滑坡机理研究
[J]. 地球科学进展, 2004, 19 (3): 443~450.
Huang Runqiu. Mechanism of large scale landslides in western China. Advance in earth sciences, 2004, 19 (3): 443~450.

[22] 刘忠玉,马崇武,苗天德,等. 高速滑坡远程预测的块体运动模型
[J]. 岩石力学与工程学报, 2000, 19 (6): 742~746.
Liu Zhongyu,Ma Chongwu,Miao Tiande,et al. Kinematic block model of long run-out prediction for high-speed landslides. Chinese Journal of Rock Mechanics and Engineering, 2000, 19 (6): 742~746.

[23] 黄润秋,裴向军,张伟锋,等. 再论大光包滑坡特征与形成机制
[J]. 工程地质学报, 2009, 17 (6): 725~736.
Huang Runqiu,Pei Xiangjun,Zhang Weifeng,et al. Further examination on characteristics and formation mechanism of Daguangbao landslide. Journal of Engineering Geology, 2009, 17 (6): 725~736.

[24] 王涛,马寅生,龙长兴,等. 四川汶川地震断裂活动和次生地质灾害浅析
[J]. 地质通报, 2008, 27 (11): 1913~1922.
Wang Tao,Ma Yinsheng,Long Changxing,et al. Fault activity of the Wenchuan earthquake in Sichuan,China and seismic secondary geohazards. Geological Bulletin of China, 2008, 27 (11): 1913~1922.

[25] 张倬元,王士天,王兰生. 工程地质分析原理
[M]. 北京: 地质出版社,1994.
Zhang Zhuoyuan,Wang Shitian,Wang Lansheng. Principles of engineering geology analysis. Beijing: Geology Press,1994.

[26] Li,X. ,Z. Zhou,H. Yu,et al. Strong motion observations and recordings from the great Wenchuan Earthquake. Earthquake Engineering and Engineering Vibration, 2008, 7 (3): 235~246.

[27] 中华人民共和国建设部,建筑抗震设计规范(GB 50011-2001)
[S].北京:中国建筑科学研究院,2001.
The Peoples Republic of China Ministry of Construction. Code for Seismic Design of Buildings(GB 50011-2001). Beijing: China Academy of Building Research,2001.

[28] 崔芳鹏,胡瑞林,殷跃平,等. 地震纵横波时差耦合作用的斜坡崩滑效应研究
[J]. 工程地质学报, 2009, 17 (4): 455~462.
Cui Fangpeng,Hu Ruilin,Yin Yueping,et al. Numerical simulation of slope collapsing and sliding due to single or combined actions of seismic p-and s-waves with time difference. Journal of Engineering Geology, 2009, 17 (4): 455~
