川藏公路茶树山滑坡特征及成因机制分析

白永健; 郑万模; 李明辉; 易志坚; 王东辉

川藏公路茶树山滑坡特征及成因机制分析

1.
中国地质调查局成都地质调查中心成都 610081;
2.
成都理工大学地质灾害防治与地质环境保护国家重点实验室成都 610059

基金项目:

地调项目:中国地质调查局项目甘孜地区地质灾害详细调查(1212010114020).

详细信息

作者简介:
白永健,主要从事工程岩土体稳定性及地质灾害调查等研究工作.Email byj209@126.com

中图分类号: TU457
计量
- 文章访问数: 3993
- HTML全文浏览量: 257
- PDF下载量: 1526
- 被引次数: 0
出版历程
- 收稿日期: 2009-12-12
- 修回日期: 2010-01-04
- 刊出日期: 2010-12-25

CHARACTERISTICS AND FORMATION MECHANISM OF CHA-SHU-SHAN LANDSLIDE ON SICHUAN-TIBET HIGHWAY

1.
Chengdu Center of China Gelogical Survey,Chengdu 610081;
2.
Station Key Laboratory of Geo-hazard Prevention and Geo-Environment Protection,Chengdu 610059

摘要

摘要: 通过对川藏公路茶树山滑坡地质环境条件的系统调查研究,分析了滑坡岩土体结构、边界条件、变形特征、影响因素,并结合3DEC数值模拟,对其变形破坏机制进行了深入的探讨。综合分析表明,滑坡位于活动断裂带内,后缘斜坡陡峭,岩体破碎,同时前缘为较厚的松散堆积体斜坡,在地震活动、降雨等影响因素的诱发作用下,滑坡成因机制主要表现为以下3个阶段:(1)倾倒拉裂阶段,滑坡受后缘地形及岩体结构控制作用较为明显,在坡体浅表层一定深度范围内出现较为强烈的倾倒拉裂变形带,产生倾倒-拉裂滑动; (2)蠕滑变形阶段,前缘松散堆积体在强大的自重推力作用下发生蠕滑变形; (3)前部锁骨段剪断,整体失稳阶段,滑坡前部锁骨段在自重推力及断层活动的持续影响下,发生剪断,控制后缘倾倒拉裂体稳定性的潜在滑面与前缘松散堆积体体内的剪切滑动面贯通,滑坡整体失稳。
- 反倾滑坡 /
- 活动断裂 /
- 成因机制 /
- 倾倒拉裂蠕滑 /
- 3DEC
Abstract: Based on the systematic investigation of cha-shu-shan landslide on Chuan-Zang highway, this paper analyzes the landslide rock and soil structures,boundary conditions,deformation characteristics,influence factors and formation mechanism,and makes a in-depth discussions combined with 3DEC numerical simulation. The comprehensive analysis shows that the landslide is located in an active fault. The back edge rock is poor,and the front loose accumulation is thick. Under seismic activity,rainfall and other factors eliciting,the failure mechanism of landslide can be divided into the following 3 stages: (1)stage of toppling and pull-splitting,the back edge landslides stabilty is controled by the topography and structure of rock mass, where formes a rather strong dumped rupture deformation belt. Then generates slippage.(2)stage of creep deformation,the front loose accumulation body occurs creep deformation in a powerful gravity thrust.(3)stage of failing,clavicle segment are cutted in the weight thrust and the continuing effects of fault activity. Then the backedge potential slide plane and front shear slip plane are linked the whole landslide fails.
- Counter-inclined slope /
- Active fault /
- Formation mechanism /
- Toppling-pull splitting-creep /
- 3DEC

HTML全文

参考文献(1)

[1] 黄润秋. 中国西南岩石高边坡的主要特征及其演化
[J]. 地球科学进展, 2005, 20 (3): 292～297.
Huang Runqiu. Main characteristics of hign rock slopes in southwestern China and their dynamic evolution. advances in earth science. 2005, 20 (3): 292～297.

[2] 中国岩石力学与工程学会地面岩石工程专业委员会, 中国地质学会工程地质专业委员会编.中国典型滑坡
[M]. 北京:科学出版社, 1988.
Chinese Society of Rock Mechanics and Engineering,Rock Engineering Committee on the ground,China Professional Committee of the Geological Society of Engineering Geology compiled. Typical slip in China,Beijing,Science Press,1988.

[3] 巨能攀, 黄润秋,涂国祥.含水砂层对堆积体稳定性的影响研究
[J].工程地质学报, 2006, 14 (4): 476～480.
Ju Nengpan, Huang Runqiu, Tu Guoxiang. FEM analysis of the effect of saturated sand seams on stability of accumulations along upper Min jiang River. Journal of Engineering Geology, 2006, 14 (04): 476～480.

[4] 张倬元, 等.工程地质分析原理
[M].北京: 地质出版社, 1994.
Zhang Zhuoyuan,Wang Shitian,Wang Lansheng. Analysis theory of engineering geology. Beijing:Geology Press, 1994.

[5] 黄润秋, 唐世强,邓辉,邹正明.皖南某高速公路四号边坡变形机理及稳定性分析
[J]. 成都理工大学学报(自然科学版).2006  33 (6): 551～556.
Huang Runqiu,et al. Characteristics and mechanism of 4th slope deformation on one expressway in the south of Anhui,China. Journal of Chengdu University of Technology(Science & Technology Edition), 2006, 33 (6): 551～556.

[6] Itasca Consulting Group, Inc. 3 Dimensional Distinct Element Code Users Guide , 2003.

[7] Chen Z,Wang X,Haberfield C,et al.A three-dimensional slope stability analysis method using the upper bound theorem,part Ⅰ: theory and methods
[J]..Int.J. of Rock Mechanics and Mining Sciences,2001,(38): 369～378.

[8] 白永健, 黄润秋,巨能攀,等.高陡岩质边坡稳定性三维离散元分析
[J].工程地质学报,2008, 16 (5): 592～597.
Bai Yongjian, Huang Runqiu, Ju Nengpan,et al. 3 dec stability analysis of high and steep rock slope,Journal of Engineering Geology, 2008, 16 (5): 592～597.

[9] 肖学沛, 李天斌,张志龙.三峡水库区严家坡滑坡成因分析及稳定性评价
[J].中国地质灾害与防治学报,2005, 16 (1): 39～43.
Xiao Xuepei, Li Tianbin, Zhang Zhilong. Causes analysis and the stability assessment of Yanjiapo Landslide in the Three Gorges Reservoir area. Chinese Journal of Geological Hazard and Control, 2005, 16 (1): 39～43.
