地质雷达在风火山隧道病害检测中的应用与结果分析

康富中; 江波; 贺少辉; 齐法琳

地质雷达在风火山隧道病害检测中的应用与结果分析

1.
北京交通大学土建学院隧道与地下工程系北京 100044;
2.
中国铁道科学研究院基础设施检测研究所北京 100044

基金项目:

铁道部重大课题:隧道衬砌状态检测技术及装备研究(2008G017-A)

详细信息

作者简介:
康富中,工程地质专业.mail: kkkangfzh@126.com

中图分类号: TU91
计量
- 文章访问数: 4063
- HTML全文浏览量: 212
- PDF下载量: 1567
- 被引次数: 0
出版历程
- 收稿日期: 2009-11-27
- 修回日期: 2010-05-24
- 刊出日期: 2010-12-25

DETECTION AND ANALYSIS OF TUNNEL DEFECTS WITH GEOLOGICAL PENETRATING RADAR AT FENGHUO MOUNTAIN

1.
The Department of Tunnel and Underground of Beijing Jiaotong University,Beijing 100044;
2.
The Testing Institute of Base-Structure of CARS,Beijing 100044

摘要

摘要: 青藏铁路全线开通运营以来,对处于高寒地区的永久冻土隧道之一的风火山隧道的质量状态首次进行了无损检测。风火山隧道处于高寒永久冻土区,隧道全部处于冻岩中,两端洞口主要为砂岩与泥岩,并且为富冰冻土。受到季节性冻融的影响,隧道病害比较突出,主要表现为衬砌裂缝,漏水涌水,衬砌酥松剥落。为了准确地掌握风火山隧道衬砌结构质量状态,本文首次应用于风火山隧道衬砌结构的质量检测。该检测设备一改传统破坏式的检测方法,具有快速、简捷、无损、灵活的特点。通过对现场数据处理分析,可以精确探测衬砌厚度,查明衬砌背后存在的空洞和回填不密实区域。检测结果表明,隧道在高寒恶劣环境中,衬砌总体外观质量尚好,但是在两端洞口段有渗水现象; 衬砌背后空洞缺陷等级为严重地段测线长度为20m,等级为极严重地段测线长度为98m; 衬砌背后回填不密实缺陷等级为严重地段测线长度为41m,等级为极严重地段测线长度为33m。检测结果与实际病害情况基本相符。
- 地质雷达 /
- 隧道 /
- 衬砌 /
- 病害 /
- 无损检测
Abstract: The soundness diagnosis testing was carried out on the quality state of a tunnel at Fenghuo Mountain tunnel.This tunnel is one of the permafrost tunnels in frost soil area along the Qinghai-Tibet Railway line.The testing was done some years later after the railway was used. The tunnel is in alpine permafrost zone.The tunnel body is in the frozen rocks.At both ends of the tunnel,the dominant rocks are sandstone and shale,where the frozen soils are ice-rich.Due to the seasonal effects of freezing and thawing,defects were appear in the tunnel more and more. The defects are manifested mainly as lining cracks,leaking and gushing water,lining crisp peeling.In order to accurately understand the quality state of the tunnel lining,the geological penetrating radar technique was used to defect and quantify the defects in the tunnel field.The technique was applied to the tunnel lining structure quality inspection.The technique changed the traditional destructive testing method.The technique is fast,simple,non-destructive,and accurate.Through the in-situ data processing and analysis,the technique can accurately detect lining thickness,find out of lining and filling the empty space behind the non-dense area.The test results show the following.The tunnel in the frozen atrocious weather environment,the lining appearance was not damaged.Seepage was found in the openings of two ends.The lining with empty is the most serious defect level and had a measured length of 20m.The line with the secondary serious defect level had a length of 98m.The lining backfill behind the non-compact class is the third serious defect level and has a measured length of 41m.The most serious level has a line length of 33m.Test results are basically consistent with the actual defect situation. The results can provide a scientific basis for normal operation of the tunnel and reliable foundation for defect treatment in the future.Practical evidence proved the use of geological penetrating radar to make health diagnostic tests for the tunnel is feasible.
- Geological penetrating radar /
- Tunnel /
- Lining /
- Damage /
- Soundness diagnosis testing

HTML全文

参考文献(1)

[1] 谢雄耀,李永胜,黄新才.地质雷达检测在保护性建筑结构加固中的应用
[J].同济大学学报, 2000, 28 (1):19～23.
Xie Xiongyao,Li Yongsheng,Huang Xincai.Application of ground penetrating radar to historical building strengthening. Joural of Tongji Uniiversity: 2000, 28 (1):19～23.

[2] 马洪蛟,李宇,蔡辉,孙典红.地质雷达探测抛填厚度研究
[J]. 南京林业大学学报(自然科学版), 2004, 28 (2):51～53.
Ma Hongjiao,Li Yu,Cai Hui,Sun Dianhong.The new application of geological radar detection technologyto enclose tideland for cultivation to throw fill. Journal of Nanjing Forestry University(Natural Sciences Edition, 2004, 28 (2):51～53.

[3] 苏红旗,杨峰,王均双,等.地质雷达信号采样定时控制
[J].中国铁道科学, 2005, 26 (3):59～63.
Su Hongqi,Yang Feng,Wang Junshuang,et al.Timing control of geological radar signals sampling. CHina Railway Science, 2005, 26 (3):59～63.

[4] 刘传孝,蒋金泉,杨永杰.地质雷达应用于探测拱桥空洞的效果验证
[J].岩土力学, 2001, 22 (1):106～108.
Liu Chuanxiao,Jiang Jinquan,Yang Yongjie. Efects of the ground penetrating radar in probing arch bridge and cavity. Rock and Soil Mechanics, 2001, 22 (1):106～108.

[5] 罗方.地质雷达在隧道健康诊断中的应用
[J].长安大学学报(自然科学版), 2006, 26 (3): 51～54.
Luo Fang. Application of geological radar in health diagnosis of tunnel. Journal of Changan University(Natural Science Edition), 2006, 26 (3):51～54.

[6] 祁明松.地质雷达在隧洞内的探测
[J]. 地球科学-中国地质大学学报, 1993, 18 (3):352～357.
Qi Mingsong. GPR sounding in tunnel. China University of Geosciences, 1993, 18 (3):352～357.

[7] 郭有劲.地质雷达在铁路隧道衬砌质量检测中的应用
[J]. 铁道工程学报, 2002, 74 (2):71～74.
Guo Youjin.Explkoration and application of geology radar for quality examination of railway tunnel lining.Journal of Rail Way Engineering Society, 2002, 74 (2):71～74.

[8] 李晋平,邵丕彦,谷牧.地质雷达在铁路隧道工程质量检测中的应用
[J].中国铁道科学, 2006, 27 (2):56～59.
Li Jinping,Shao Piyan,Gu Mu.Application and analysis of GPR in railway tunnel engineering quality inspection. China Railway Science, 2006, 27 (2):56～59.

[9] 雷刚,杨林德.公路隧道衬砌质量检测中电磁波无损检测方法的应用研究
[J].岩石力学与工程学报, 2005, 24 (增1): 5081～5085.
Lei Gang,Yang Linde. Application study on nondestructive dete ction method of electrom agnetic ve in road tunnel lining quality detection. Journal of Rock Mechanics and Engineering, 2005, 24 (s1): 5081～5085.

[10] 高鹤.探地雷达在隧道混凝土衬砌检测中的应用
[J].低温建筑技术, 2009, 8 ,77～78.
Gao He. Ground penetrating radar applied in the detection of tunnel concrete.Low Temperature Architecture Technology, 2009, 8 ,77～78.

[11] 高鹤.隧道混凝土衬砌质量检测方法研究
[J].甘肃科技, 2009, 12 ,127～129.
Gao He. The study of tunnel concrete lining quality detection method.Gansu Science and Technology, 2009, 12 ,127～129.

[12] 《铁路运营隧道衬砌安全等级评定暂行规定》(铁运函

[2004] 174号) .
Evaluation of safety classification for railway tunnel lining)(Rail Transportation Letter

[2004] .No.174.
