FRICTIONAL RESISTANCE INFLUENCE ON INTERNAL FORCE OF FRAME BEAMS USED IN ROADCUT SLOPE
-
摘要: 边坡防护中的锚固格构梁多采用Winkler假设计算内力,设计者通常忽略了边坡岩土体和格构之间摩擦阻力的影响。摩擦阻力对于预应力而言较小,但确实存在,在未加预应力锚固格构梁中不应忽略。本文提出了一种简单有效的计算方法,并结合工程实例,使格构梁的设计得以优化。Abstract: Frame beams in slope protection are often analyzed for internal forces using the Winkler model. Designers usually overlook the frictional force between the frame beam and the slope. Even though the frictional resistance is much smaller than the pre-stress of an anchor bolt, it does exist. Therefore, it should not be ignored in a non-pre-stressed anchor bolt frame. This paper introduces a simple and effective method for calculating internal force with a case study. The results show that this method can help optimize design of the frame beam.
-
Key words:
- Frame beam /
- Frictional resistance /
- Winkler supposition /
- Slope
-
[1] 杨明,胡厚田,卢才金等.路堑土质边坡加固中预应力锚索框架的内力计算
[J].岩石力学与工程学报,2002,21(9):1383~1386.Yang M ing,Hu Houtian,Lu Caijin,et al..Calculation of inter2nal forces for p restressed anchor cable frame used in reinforced roadcut soil slope.Chinese Journal of Rock Mechanics and Engineering,2002,21(9):1383~1386.
[2] 周德培,张俊云.植被护坡工程技术
[M].北京:人民交通出版社,2003.Zhou Depei,Zhang Junyun.Engineering Technique of Vegetation and Slope Protection.Beijing:China Communication Press,2003.
[3] 秦四清.基坑支护设计的弹性抗力法
[J].工程地质学报,2000,8(4):481~487.Q in Siqing.The elastic resistance method for design of foundation p it supporting.Journal of Engineering Geology,2000,8(4):481~487.
[4] 谈至明.具有水平摩阻力的弹性地基梁上的解
[J].力学与实践,1997,19(3):33~35,Tan Zhim ing.The solution of elastic foundation beam considering frictional resistance.Mechanics in engineering,1997,19(3):33~35.
[5] 胡人礼.桥梁力学
[M].北京:中国铁道出版社,1999.Hu Renli.B ridge Mechanics.Beijing:Chinese Railway Publishing House,1999. -
