LANDSLIDE MECHANISM AND TREATMENT MEASURES FOR HIGH FILL SLOPE AT AIRPORT IN SOUTHWESTERN CHINA
-
摘要: 西南某高填方机场土石方工程竣工后不久遭遇了持续半月的强降水，在一次突发暴雨后4h，边坡发生了滑塌。采用监测、检测、现场调查、原位试验、室内试验、数值模拟等手段进行综合分析。结果认为，该机场高填方边坡滑塌主要是采用含碎石黏性土填筑的土面区、边坡影响区，因强夯补强破坏了填筑体内原有的碎石排水层，造成了采用碎石填筑的道槽区入渗的降水不能及时排出而引发的高地下水压力、渗透变形、浸泡软化等共同作用所致。最后针对性地采取填筑体顶面薄膜覆盖，坡面出水点网装级配碎石反滤和引流、滑塌坡面袋装碎石回填的应急处理措施，以及填筑体顶面黏性土回填、坡面碎石换填、仰斜管排水的永久处理方法，有效地控制了边坡的进一步变形、滑塌，取得了良好的灾害治理效果。Abstract: A high fill airport in southwestern China suffered a half month of heavy rainfall immediately after its earthwork has been completed. A landslide occurred at 4 hours after the sudden rainstorm. This paper uses the methods of surveillance, detection, scene investigation, in situ tests, laboratory test and numerical simulation and makes a comprehensive analysis. The slope sliding is due to the following aspects. The embankment of dynamic compaction reinforcement destroyed the original gravel drainage layer in the body of the soil surface area. The affected slope area is the ground with gravel filling of cohesive soil. The rainfall can not be discharged from the channel slot area. High groundwater pressure, seepage deformation, soak softening, and others cause the slide. The emergency measures include film covering the top surface of the filling body, network installation graded gravel filtration and drainage on slope water point, sliding slope gravel bags backfill and permanent disposal method of filling the top of cohesive backfill, slope gravel replacement and yang inclined tube drainage. They effectively control the further slump deformation and slide, achieve good results.
-
Key words:
- High fill /
- The landslide /
- Rainfall infiltration /
- Soaked to soften /
- Water pressure /
- Numerical analysis
-
图 7 T01-T06监测点位移量及位移速率曲线
a. H向累计位移量(mm)；b. P向累计位移量(mm)；c. H向位移速率(mm ·d-1)；d. P向位移速率(mm ·d-1)
Figure 7. T01-T06 displacement and displacement rate curve of the monitoring points
图 13 降雨入渗、地下水渗流与斜坡失稳关系示意图
Figure 13. The relationship schematic diagram of slope instability relate to groundwater flow and infiltration
图 17 不同降雨历时土体体积含水率等值线图
a.降雨历时1h；b.降雨历时12h；c.降雨历时24h；d.降雨历时48h；e.降雨历时72h
Figure 17. Soil volumetric water content contour map of different rainfall duration
图 18 不同降雨历时体积含水率-深度分布曲线
Figure 18. Volumetric water content-depth distribution curve of different rainfall duration
图 19 不同降雨历时孔隙水压力-深度分布曲线
Figure 19. Pore water pressure-depth distribution curve of different rainfall duration
图 20 各降雨历时边坡稳定性和滑带分布图
a.降雨历时1h；b.降雨历时24h；b.降雨历时48h；d.降雨历时72h
Figure 20. Slope stability and slip band profile of different rainfall duration
图 21 降雨历时-边坡稳定性分布曲线
Figure 21. Distribution curve of rainfall duration and slop stability
图 22 天然工况下应变及位移矢量分布图(单位：mm)
Figure 22. Strain and displacement vector map in natural conditions (displacement unit: mm)
图 23 降雨工况下应变及位移矢量分布图(单位：mm)
Figure 23. Strain and displacement vector map in rainfall conditions
表 1 建模物理力学参数
Table 1. Modeling of physical and mechanical parameters
分类 容重
/kN·m-3黏聚力
/kPa摩擦角
/(°)模量
/kPa泊松比 渗透系数
/m·s-1碎石 2000 2.0 29.0 3.4E4 0.21 1.9E-2 含碎石
红黏土1850 41 22.0 6.1E3 0.25 2.88E-6 白云岩 2720 5400 44.0 1.12E7 0.20 4.2E-10
下载: 导出CSV
-
Cai Z L, Huang L P. 2005. Elastic rheological mechanics[M]. Beijing:Atomic Press. Chen T L, Deng G, Chen S S, et al. 2006. Effects of fissures on stability of unsaturated soil slope[J]. Chinese Journal of Geotechnical Engineering, 28 (2):210~215. He Z Y, Sun Y, Zhao C, et al. 2001. Application of impact compaction in Wanzhou airport high embankment[J]. Journal of Chongqing Jiaotong Unviersity, 20 (2):83~86. http://en.cnki.com.cn/Article_en/CJFDTOTAL-CQJT200102018.htm Li H L, Huang R Q, Wu L Z, et al. 2013. Rainfall infiltration coupling process and stability analysis of a heterogeneous soil slope[J]. Hydrogeology & Engineering Geology, 40 (4):70~76. http://en.cnki.com.cn/Article_en/CJFDTOTAL-SWDG201304014.htm Luo P P, Wang L F, Gao X W, et al. 2011. Landslide mechanism of dynamically compacted slag slope under rainfall infiltration[J]. Journal of Engineering of Geology, 19 (6):844~851. http://en.cnki.com.cn/Article_en/CJFDTOTAL-GCDZ201106007.htm Qi G Q, Huang R Q, Su B Y, et al. 2003. Numeric simulation on rainfall infiltration on rock slope[J]. Chinese Journal of Rock Mechanics and Engineering, 22 (4):625~629. http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSLX200304030.htm Richards L A. 1931. Capillary conduction of liquids in porous mediums[J]. Physics, 1 (5):318~333. doi: 10.1063/1.1745010 Wei Y J, Zhu H L, Zhuang M G, et al. 2016. Formation mechanism of Wangshan-Zhuangkousi landslide in Emei city, Sichuan province[J]. Journal of Engineering of Geology, 24 (3):477~483. Xie C Q, Liu H C, Gan H Y. 2001. Study of treatment method for airport high fill tamping foundation in mountainous area[J]. Site Investigation Science and Technology, (5):11~15. Xu Z M, Zhang Z Y, Xu Q, et al. 2004. Dynamic stability analysis of high fill slope of Jiuzhai-Huanglong airfield[J]. Chinese Journal of Rock Mechanics and Engineering, 23 (11):1883~1890. http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSLX200411022.htm Xue Y Q, Wu J C. 2010. Groundwater dynamics[M]. Beijing:Geological Publishing Press. Zhang Z Q, Wang S T, Wang L S, et al. 2009. Engineering geology analysis principle[M]. Beijing:Geological Publishing Press. Zhu W, Cheng L J, Chen X D, et al. 2006. Some fundamental problems of unsaturated seepage[J]. Chinese Journal of Geotechnical Engineering, 28 (2):235~240. http://en.cnki.com.cn/Article_en/CJFDTOTAL-YTGC200602017.htm 蔡中林, 黄临平. 2005.弹性流变力学[M].北京:原子能出版社. 陈铁林, 邓刚, 陈水生, 等. 2006.裂隙对非饱和土边坡稳定性的影响[J].岩土工程学报, 28 (2):210~215. http://www.cnki.com.cn/Article/CJFDTOTAL-LJGC201404032.htm 何兆益, 孙勇, 赵川, 等. 2001.强夯法在万州五桥机场高填方工程中的应用[J].重庆交通学院学报, 20 (2):83~86. http://www.cnki.com.cn/Article/CJFDTOTAL-CQJT200102018.htm 李海亮, 黄润秋, 吴礼舟, 等. 2013.非均质土坡降雨入渗的耦合过程及稳定性分析[J].水文地质工程地质, 40 (4):70~76. http://www.cnki.com.cn/Article/CJFDTOTAL-SWDG201304014.htm 罗平平, 王兰甫, 高献伟, 等. 2011.降雨入渗下高填强夯矿渣边坡滑坡机理研究[J].工程地质学报, 19 (6):844~851. http://www.gcdz.org/CN/abstract/abstract11079.shtml 戚国庆, 黄润秋, 速宝玉, 等. 2003.降雨诱发滑坡机理及其评价方法研究[J].岩石力学与工程学报, 22 (4):625~629. http://cdmd.cnki.com.cn/Article/CDMD-10616-2005117094.htm 魏云杰, 褚宏亮, 庄茂国, 等. 2016.四川省峨眉山市王山-抓口寺滑坡成因机理研究[J].工程地质学报, 24 (3):477~483. http://www.gcdz.org/CN/abstract/abstract11995.shtml 谢春庆, 刘汉超, 甘厚义. 2001.山区机场高填方夯实地基处理方法的研究[J].勘察科学技术, (5):11~15. http://www.cnki.com.cn/Article/CJFDTOTAL-KCKX200105002.htm 徐则民, 张倬元, 许强, 等. 2004.九寨黄龙机场填方高边坡动力稳定性分析[J].岩石力学与工程学报, 23 (11):1883~1890. doi: 10.3321/j.issn:1000-6915.2004.11.018 薛禹群, 吴吉春. 2010.地下水动力学(第三版)[M].北京:地质出版社. 张倬元, 王士天, 王兰生.等. 2009.工程地质分析原理(第三版)[M].北京:地质出版社. 朱伟, 程南军, 陈学东, 等. 2006.浅谈非饱和土渗流的几个基本问题[J].岩土工程学报, 28 (2):235~240. http://www.cnki.com.cn/Article/CJFDTOTAL-YTGC200602017.htm -
