FENG Wenkai, ZHANG Guoqiang, BAI Huilin, ZHOU Yulong, XU Qiang, ZHENG Guang. 2019: A PRELIMINARY ANALYSIS OF THE FORMATION MECHANISM AND DEVELOPMENT TENDENCY OF THE HUGE BAIGE LANDSLIDE IN JINSHA RIVER ON OCTOBER 11, 2018. JOURNAL OF ENGINEERING GEOLOGY, 27(2): 415-425. doi: 10.13544/j.cnki.jeg.2018-392
Citation: FENG Wenkai, ZHANG Guoqiang, BAI Huilin, ZHOU Yulong, XU Qiang, ZHENG Guang. 2019: A PRELIMINARY ANALYSIS OF THE FORMATION MECHANISM AND DEVELOPMENT TENDENCY OF THE HUGE BAIGE LANDSLIDE IN JINSHA RIVER ON OCTOBER 11, 2018. JOURNAL OF ENGINEERING GEOLOGY, 27(2): 415-425. doi: 10.13544/j.cnki.jeg.2018-392

A PRELIMINARY ANALYSIS OF THE FORMATION MECHANISM AND DEVELOPMENT TENDENCY OF THE HUGE BAIGE LANDSLIDE IN JINSHA RIVER ON OCTOBER 11, 2018

doi: 10.13544/j.cnki.jeg.2018-392
Funds:

the Team Project of Independent Research of SKLGP SKLGP2016Z001

the National Natural Science Foundation of China 41572291

the Sichuan Provincial Youth Science and Technology Innovation Team Special Projects of China 2017TD0018

  • Received Date: 2018-11-29
  • Rev Recd Date: 2019-01-23
  • Publish Date: 2019-04-25
  • On October 11, 2018, a massive landslide occurred in Baige Village, Boluo Town, Jiangdacounty, Changdu city, Tibet. About 3, 165×104 cubic meter of a mountain mass rushed into the Jinsha River at a high speed, thus forming a barrier dam. At 9:00 on October 13, the body of the barrier dam was washed away by natural aerial drainage and the threat of forming a barrier lake was resolved. On November 3, only 23 days later, the high slip mass of 215×104 cubic meter at the back edge of the landslide occurred sliding failure again. The high-speed slip mass scraped the slope along the way and then rushed into the Jinsha River, forming a barrier dam again. This paper held the view that the landslide happened in Baige Village was thought to be mainly controlled by the next branch margin thrust fault f2, then finally generated buckling failure of the overall instability of the landslide with the influence of a long-term gravity unloading, rainfall and repeated infiltration of groundwater. The process of slip deformation and failure can be divided into five stages:trailing creep and settlement under the fault phase(Ⅰ), slope crack development, penetration stage(Ⅱ), overall launch of the "locking-fix end" cutting stage(Ⅲ), a stage with high moving speed(Ⅳ), collided, crushing and dam accumulation stage(Ⅴ). The failure mode of the first-stage deformation and failure mechanism can be summed up as creep-slip type-down fault type-shearing type-ski-jump type, and the failure mode is shown as the thrust type. In the later stage, the free surface condition of the slope is better, and the traction type can remain as the main failure mode. On this basis, combined with the residual strong deformation block(K1, K2, K3) and morphological characteristics and deformation signs of the surrounding influence zone, this paper predicted and analyzed the deformation and failure characteristics and development trend of the block, deeming that strong deformation areas can be destroyed by gradual disintegration. And these research findings can provide some reference for the monitoring, survey and governance of the future plan making and implementation.
  • loading
  • Caine J S, Evans J P, Forster C B. 1996. Fault Zone Architecture and Permeability Structure[J]. Geology, 24(11):1025-1028. doi: 10.1130/0091-7613(1996)024<1025:FZAAPS>2.3.CO;2
    Feng W K, Hu Y P, Xie J Z, et al. 2016. Disaster mechanism and stability analysis of shattered bedding slopes triggered by rainfall-A case study of Sanxicun landslide[J]. Chinese Journal of Rock Mechanics and Engineering, 35(11):2197-2207. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yslxygcxb201611004
    Gehle C, Kutter H K. 2003. Breakage and shear behavior of intermittent rock joints[J]. International Journal of Rock Mechanics & Mining Sciences, 40(5):687-700. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=CC026531435
    He S M, Bai X Q, Ouyang C J, et al. 2017. On the survey of giant landslide at Xinmo village of Diexin town, Maoxian County, Sichuan Province, China[J]. Mountain Research, 35(4):598-603.
    Huang N E, Shen Z, Long S R, et al. 1998. The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis[J]. Proceedings A, 454 (1971):903-995.
    Huang X, Yang W M, Zhang C S, et al. 2013. The formation mechanism of Suoertou landslide in Pingding-Huama fault zone, Southern Gansu[J]. Geological Bulletin of China, 32 (12):1936-1942. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgqydz201312007
    Melons H J. 1996. Dynamical weakening of faults by acoustic fluidization[J]. Nature, 379 (6566):601-606. doi: 10.1038/379601a0
    Xiao S R, Liu D F, Hu Z Y. 2010. Engineering geologic study of three actual dip bedding rock slides associated with reservoirs in the world[J]. Joumal of Engineering Geolpgy, 18(1):52-59.
    Xiao Y J, Yin K L. 2010. Analysis of rockmass' stability at Baitupo slope in Badong new town, Hubei Province[J]. The Chinese Journal of Geological Hazard and Control, 21(4):44-47. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdzzhyfzxb201004008
    Xu Q, Li W L, Dong X J, et al. 2017. The Xinmocun landslide on June 24, 2017 in Maoxian, Sichuan:Characteristics and failure mechanism[J]. Chinese Journal of Rock Mechanics and Engineering, 36(11):2612-2628.
    Xu Q, Tang M G, Xu K Y, et al. 2008. Research on space-time evolution laws and early warning-prediction of landslides[J]. Chinese Journal of Rock Mechanics and Engineering, 27(6):1104-1112. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yslxygcxb200806003
    Xu Q, Zeng G, Li W L, et al. 2018. Study on successive landslide damming events of Jinsha River in Baige Village on Octorber 11 and November 3, 2018[J]. Joumal of Engineering Geology, 26(6):1534-1551.
    Xu Y Q, Yin Z Q, Sa L P. 2016. Developing characteristics and evolution process of Ganjiazhai large scale landslide in Ludian 8.03 earthquake area of northeast Yunnan[J]. Joumal of Engineering Geolpgy, 24(4):550-558.
    Xu Z M, Liu W L, Huang R Q. 2011. Engineering geological characteristics of Zhaizicun giant ancient landslide along Jinsha River and its occurrence mechanisms[J]. Chinese Journal of Rock Mechanics and Enginneering, 30 (S2):3539-3550.
    Zhang L J, Wu G H, He S, et al. 2016. Structural diagenesis in carbonate fault damage zone:A case study of the No.1 fault zone in the Tarim Basin[J]. Acta Petrologica Sinica, 32(3):922-934. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201603023
    冯文凯, 胡云鹏, 谢吉尊, 等. 2016.顺层震裂斜坡降雨触发灾变机制及稳定性分析——以三溪村滑坡为例[J].岩石力学与工程学报, 35(11):2197-2207. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yslxygcxb201611004
    何思明, 白秀强, 欧阳朝军, 等. 2017.四川省茂县叠溪镇新磨村特大滑坡应急科学调查[J].山地学报, 35(4):598-603. http://d.old.wanfangdata.com.cn/Periodical/sdxb201704020
    黄晓, 杨为民, 张春山, 等. 2013.甘肃南部坪定-化马断裂带锁儿头滑坡成因机制[J].地质通报, 32(12):1936-1942. http://d.old.wanfangdata.com.cn/Periodical/zgqydz201312007
    肖诗荣, 刘德富, 胡志宇. 2010.世界三大典型水库型顺层岩质滑坡工程地质比较研究[J].工程地质学报, 18(1):52-59. doi: 10.3969/j.issn.1004-9665.2010.01.007
    肖拥军, 殷坤龙. 2010.湖北省巴东新城白土坡斜坡岩体稳定性分析[J].中国地质灾害与防治学报, 21(4):44-47. doi: 10.3969/j.issn.1003-8035.2010.04.008
    徐永强, 殷志强, 撒兰鹏. 2016.鲁甸8.03地震区甘家寨特大型滑坡发育特征及演化过程研究[J].工程地质学报, 24(4):550-558. http://www.gcdz.org/CN/abstract/abstract12004.shtml
    徐则民, 刘文连, 黄润秋. 2011.金沙江寨子村巨型古滑坡的工程地质特征及其发生机制[J].岩石力学与工程学报, 30 (S2):3539-3550. http://www.cnki.com.cn/Article/CJFDTOTAL-YSLX2011S2025.htm
    许强, 李为乐, 董秀军, 等. 2017.四川茂县叠溪镇新磨村滑坡特征与成因机制初步研究[J].岩石力学与工程学报, 36(11):2612-2628. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yslxygcxb201711002
    许强, 汤明高, 徐开洋, 等. 2008.滑坡时空演化规律及预警预报研究[J].岩石力学与工程学报, 27(6):1104-1112. doi: 10.3321/j.issn:1000-6915.2008.06.003
    许强, 郑光, 李为乐, 等. 2018年10月和11月金沙江白格两次滑坡-堰塞堵江事件分析研究[J].工程地质学报, 26(6): 1534-1551.
    张丽娟, 邬光辉, 何曙, 等. 2016.碳酸盐岩断层破碎带构造成岩作用——以塔中Ⅰ号断裂带为例[J].岩石学报, 32 (3):922-934. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98201603023
