| Citation: | ZHENG Guang, XU Qiang, JU Yuanzhen, LI Weile, ZHOU Xiaopeng, PENG Shuangqi. 2018: THE PUSACUN ROCKAVALANCHE ON AUGUST 28, 2017 IN ZHANGJIA-WAN NAYONGXIAN, GUIZHOU: CHARACTERISTICS AND FAILURE MECHANISM. JOURNAL OF ENGINEERING GEOLOGY, 26(1): 223-240. doi: 10.13544/j.cnki.jeg.2018.01.023
|
THE PUSACUN ROCKAVALANCHE ON AUGUST 28, 2017 IN ZHANGJIA-WAN NAYONGXIAN, GUIZHOU: CHARACTERISTICS AND FAILURE MECHANISM
doi: 10.13544/j.cnki.jeg.2018.01.023
-
Abstract
A large scale of mountain rock avalanche occurred in Pusa village, Zhangjiawan town, Nayong county, Guizhou Province at about 10:30 on August 28, 2017. The rock mass with the volume of 49.1×104 m3 moved down and scraped the original loose deposits and finally formed deposits of 82.3×104 m3, which destroyed parts of Pusa village, resulted in the death of 26 persons and missing of 9 persons. Based on site investigation, unmanned aerial vehicle(UAV)photography and ground based synthetic aperture radar(GBSAR)monitoring and other technologies, this paper provides a detailed description on the characteristics and a comprehensive analysis on the dynamic process and failure mechanism of the rock avalanche. The preliminary study suggested that the rock masses of the source area were shattered due to the underground mining activities. The shattered rock masses suffered long-term effects of gravity, which eventually resulted the failure of the rock masses. The movement of the rock avalanche lasted for 7 minutes and 21 seconds in which the main rock masses failure lasted for only 26 seconds with the long runout of 788 m and the maximum speed of 43.83 m·s-1, belonging to typical high speed and long runout rock avalanche. There will be a big attribution if such case can be studied further. It can provide the significant experience on dealing with this kind of rock masses failure and how to provide advice on early warning and remediation project on similar cases in southwestern mountain areas of China. -
-
References
Charrière, M Humair, F Froese, C, et al. 2016. from the source area to the deposit:collapse, fragmentation, and propagation of the Frank Slide[J]. Geological Society of America Bulletin, 128(1-2):332-351. https://www.researchgate.net/profile/Florian_Humair/publication/281236815_From_the_source_area_to_the_deposit_Collapse_fragmentation_and_propagation_of_the_Frank_Slide/links/55def1a008ae45e825d3bc4f.pdf?origin=publication_listDong X J, Pei X J, Huang R Q. 2015. The Longchangzhen collapse in Kaili, Guizhou:characteristics and failure causes[J]. The Chinese Journal of Geological Hazard and Control, 26(3):3-9. https://www.researchgate.net/profile/Mark_PurnellHan Z H, Chen X, Wang X L. 2017. Risk Assessment for Luojiaqinggangling rockfall[J]. Journal of Engineering Geology, 25(2):520-530. https://www.researchgate.net/profile/Meho_Sasa_Kovacevic/publication/283825479_A_Framework_for_Risk_Management_in_Rockfall_Protection/links/5673e0ca08ae04d9b09be69b.pdf?inViewer=0&pdfJsDownload=0&origin=publication_detailHsü K J. 1975. Catastrophic Debris Streams(Sturzstroms) Generated by Rockfalls[J]. GSA Bulletin, 86(1):129-140. doi: 10.1130/0016-7606(1975)86<129:CDSSGB>2.0.CO;2Li T F, Chen H T, Wang R Q. 2016. Formation mechanism of Yanchihe landslide in Yichang city, Hubei province[J]. Journal of Engineering Geology, 24(4):578-583. https://www.sciencedirect.com/science/article/pii/S0013795209001562Liu C Z. 2006. Basic problem on emergency disposition of abrupt heavy geological disaster[J]. Journal of Natural Disasters, 15(3):24-30. http://en.cnki.com.cn/Article_en/CJFDTOTAL-JYRJ201405003.htmLiu C Z. 2009. Landslide geohazard induced by undermining[C]//Theory and Its Application on Mega-geo-Hazards Mitigation. Beijing: Science Press.Liu C Z. 2014. Genetic Types of Landslide and Debris Flow Disasters in China[J]. Geological Review, 60(4):858-868. http://en.cnki.com.cn/Article_en/CJFDTotal-DZLP201404018.htmMonserrat O, Moya J, Luzi G, et al. 2013. Non-interferometric GB-SAR measurement:application to the Vallcebre landslide(eastern Pyrenees, Spain)[J]. Natural Hazards and Earth System Sciences, 13(7):1873-1887. doi: 10.5194/nhess-13-1873-2013Nichol D. 2001. Landslides and Landslide Management in South Wales[J]. Quarterly Journal of Engineering Geology and Hydrogeology, 34(4):415-416. http://www.worldcat.org/title/landslides-and-landslide-management-in-south-wales/oclc/44737544Ouyang G, Lan Z X. 2009. Construction Report Design of Collapse Geological Hazard Treatment Project of Pusa Coal Mine in Zhangjiawan Town, Nayong County[R]. Guiyang: Guizhou Dikuang Engineering Investigation Corporation.Ouyang G, Wang J. 2010. Mining landscape environmental protection and reservoir recovery scheme of Pusa coal mine in zhangjiawan town, Nayong county[R]. Guiyang: Guizhou Dikuang Engineering Investigation Corporation.Peng D L, Xu Q, Dong X J, et al. 2017. Accurate and Efficient Method for Loess Landslide Fine Mapping with High Resolution Close-Range Photogrammetry[J]. Journal of Engineering Geology, 25(2):424-435. doi: 10.1007/978-3-319-55342-9_1/fulltext.htmlScheidegger A E. 1973. On the prediction of the reach and velocity of catastrophic landslides[J]. Rock Mechanics, 5 (4):231-236. doi: 10.1007/BF01301796Wang D Y, et al. 2016. an Emergency Investigation Report of the Collapse of Geological Disasters in the Laoyingyan of Pusa Village in Zhangjiawan Town, Nayong County[R]. 106 Geological Party, Zunyi: Guizhou Bureau of Geology and Minerals Exploration and Development.Wang S J, Huang D C. 2004. Centurial Achievements of Chinese Engineering Geology[M]. Beijing:Geologic Publishing House.Wang Y C, Ju N P, Zhao J J, et al. 2013. Formation mechanism of landslide above the mined out area in gently inclined coal beds[J]. Journal of Engineering Geology, 21(1):61-68. http://en.cnki.com.cn/Article_en/CJFDTOTAL-KXZB201309011.htmXu Q, Li W L, Dong X J, et al. 2017. The Xinmocun landslide on June 24, 2017 in Maoxian, Sichuan:characteristics and failure mechanism[J]. Chinese Journal of Rock Mechanics and Engineering, 36(11):2612-2628. https://www.researchgate.net/publication/320318336_Failure_mechanism_and_kinematics_of_the_deadly_June_24th_2017_Xinmo_landslide_Maoxian_Sichuan_ChinaXu Q, Huang R Q, Yin Y P, et al. 2009. The Jiweishan landslide of June 5, 2009 in Wulong, Chongqing:Characteristics and failure mechanism[J]. Journal of Engineering Geology, 17(4):433-444. http://en.cnki.com.cn/Article_en/CJFDTOTAL-GCDZ200904002.htm董秀军, 裴向军, 黄润秋. 2015.贵州凯里龙场镇山体崩塌基本特征与成因分析[J].中国地质灾害与防治学报, 26(3):3-9. http://mall.cnki.net/magazine/Article/ZGDH201503029.htm韩振华, 陈鑫, 王学良, 等. 2017.四川罗家青杠岭崩塌风险的定量评价研究[J].工程地质学报, 25(2):520-530. http://www.gcdz.org/CN/abstract/abstract12379.shtml李腾飞, 陈洪涛, 王瑞青. 2016.湖北宜昌盐池河滑坡成因机理分析[J].工程地质学报, 24(4):578-583. http://www.gcdz.org/CN/abstract/abstract12007.shtml刘传正. 2006.重大突发地质灾害应急处置的基本问题[J].自然灾害学报, 15(3):24-30. http://www.cqvip.com/QK/90959A/201306/48188485.html刘传正. 2009. 采矿引发的山体开裂崩滑灾害[C]//重大地质灾害防治理论与实践. 北京: 科学出版社.刘传正. 2014.中国崩塌滑坡泥石流灾害成因类型[J].地质论评, 60(4):858-868. https://www.wenkuxiazai.com/doc/8512fb07770bf78a64295437.html欧阳刚, 兰中孝. 2009. 纳雍县张家湾镇普洒煤矿崩塌地质灾害治理工程施工图设计[R]. 贵阳: 贵州地矿工程勘察总公司.欧阳刚, 王江. 2010. 纳雍县张家湾镇普洒煤矿矿山地质环境保护与治理恢复方案[R]. 贵阳: 贵州地矿工程勘察总公司.彭大雷, 许强, 董秀军, 等. 2017.基于高精度低空摄影测量的黄土滑坡精细测绘术[J].工程地质学报, 25(2):424-435. http://www.gcdz.org/CN/abstract/abstract12368.shtml王得原, 等. 2016. 纳雍县张家湾镇普洒村老鹰岩组崩塌地质灾害应急调查报告[R]. 遵义: 贵州省地质矿产勘查开发局一〇六地质大队.王思敬, 黄鼎成. 2004.中国工程地质世纪成就[M].北京:地质出版社.王玉川, 巨能攀, 赵建军, 等. 2013.缓倾煤层采空区上覆山体滑坡形成机制分析[J].工程地质学报, 21(1):61-68. http://www.gcdz.org/CN/abstract/abstract11249.shtml许强, 李为乐, 董秀军, 等. 2017.四川茂县叠溪镇新磨村滑坡特征与成因机制初步研究[J].岩石力学与工程学报, 36(11):2612-2628. https://mall.cnki.net/qikan-GCDZ201005004.html许强, 黄润秋, 殷跃平, 等. 2009.2009年6.5重庆武隆鸡尾山崩滑灾害基本特征与成因机理初步研究[J].工程地质学报, 17(4):433-444. http://www.gcdz.org/CN/abstract/abstract8436.shtml -
Proportional views
Figures(24)
- Ethics Statement
- Brief Introducation
- Indexing & Indicator
- Reviewers
- Guide to Authors
- Subscriptions
- ISSN 1004-9665
- CN 11-3249/P
About Journal
- Sponsor: Institute of Electronics, Chinese Academy of Sciences (IECAS) ， China Radar Industry Association
- Phone: 010－82998121，82998124
- Email：gcdz@mail.igcas.ac.cn
Contacts Us
Supported by: Beijing Renhe Information Technology Co. Ltd
Support:
info@rhhz.net
Export File
Citation
Format
Content
DownLoad:
- Figure 1. Pre-sliding and post-sliding images of Pusacun rockavalanche
- Figure 2. Flowchart indicating the data and methods used in this study
- Figure 3. Geological map of the investigated area showing the outline of 8.28 Pusacun rockavalanche
- Figure 4. The stratums and their distribution in Pusacun rockavalanche source area
- Figure 5. 3D satellite image of the investigated area showing the outline of Pusacun rockacalanche(the image was taken on Mar. 18 2014, copyright@Google Earth)
- Figure 6. Images of the rockavalanche source area showing the cracks
- Figure 7. Images of the rockavalanche source area
- Figure 8. The runaway process of the rockmass in source area
- Figure 9. The runaway process of rightside of rockmass in source area
- Figure 10. Conceptual models of formation and development process of the unstable rock mass in the source area
- Figure 11. Avalanche source area and depositional area of Pusacun rockavalanche
- Figure 12. Pre-sliding and post-sliding DEMs of Pusacun rockavalanche
- Figure 13. 3D model of Pusacun rockavalanche showing the source area and transportation area
- Figure 14. 3D aerial image of the depositional area of Pusacun rockavalanche
- Figure 15. Cross section of Pusacun rockavalanche
- Figure 16. Velocity profile of Pusacun rockavalanche
- Figure 17. The unstable rock masses surrounding the source area
- Figure 18. The unstable rock mass on the rear of the source area
- Figure 19. The unstable rock mass on the north side of the source area
- Figure 20. The unstable rock mass on the south side of the source area
- Figure 21. Cracks on the unstable rock mass of the south side of the source area
- Figure 22. The displacement monitoring curve of the unstable rock mass in main scarp by GBSAR
- Figure 23. The displacement monitoring curve of the unstable area by Beidou Monitoring System
- Figure 24. Cumulative curve of rainfall prior to rockavalanche occurrence in Zhangjiawan town near the Pusacun rockavalanche
